MICRO-EPSILON C-Box/2A Operating Instructions Manual page 49

Operation
Analog output
Fields with a grey
background re-
quire a selection.
Dark bordered
1) Only one measured value can be transmitted.
fields require the
Value
specification of a
value.
C-Box/2A
Output signal Fixed output value
1
Sensor 1/2: value
Sensor 1/2: intensity
Sensor 1/2: shutter speed
Sensor 1/2: reflectivity
C-Box/2A: value
Output area Inactive / 0V ... 5V / 0V ... 10V / -5V ... 5V /
-10V ... 10V / 4mA ... 20mA
Scaling Standard scaling
Two-point scaling
Two-point Start of range in mm
scaling (dis-
End of range in mm
placement and
factor)
Output Min to The sensor signal,
value Max - the C-Box/2A result
value in or a fixed value within
V resp. the output range can
mA serve as data source.
Specification of the
analog output, cur-
rent or voltage with
selectable value
range.
Standard scaling
outputs the entire
measuring range of
the sensor/controller.
Two-point scaling re-
quires the indication
Value
of the start and the
Value
end of the measu-
ring range, value
range: from -1024 to
1024 mm.
