It is only possible to operate the controller via a Web interface. The last setting applies. Do not forget to save.
Overview
Language selection
Measuring program
Sensors
Measuring rate
Filter/Averaging/Error handling in
inside C-Box/2A
Zeroing / Mastering
Digital interfaces
Analog outputs
Digital, ports
Output data rate
Trigger mode
Synchronization
Load/save settings
Extras
C-Box/2A
Operating Menu
General
System / English / German
Measuring to be effected
Sensor 1, Sensor 2 (Sensor selection, value averaging, laser)
Display synchronization mode, selection of measuring rate
Measured value averaging, Error handling in the case of no valid mea-
sured value
Mastering active or inactive, master value in mm
Digital interfaces selection, Data selection, Ethernet settings, Settings
USB
Output signal, Output area, Scaling
Digital input, Digital outputs
Specifying measurement, reduction of measured values
Selected mode
Synchronization mode
Save to setup number, Load from setup number, Load settings, Man-
age settings on PC
Language, Factory defaults, Reset of controller
