MICRO-EPSILON C-Box/2A Operating Instructions Manual page 29

Operation
Measuring program
i
Fields with a grey
background re-
quire a selection.
Dark bordered
fields require the
Value
specification of a
value.
C-Box/2A
Select the Measuring to be effected from following list:
The selected measuring program is used as the standard measuring program on startup.
Measuring value sensor 1
Thickness sensor 1 - 2
Step sensor 1 - 2
Measuring value of sensor connected
at port 1.
Calculates the thickness of the dis-
tance between the two sensors 1/2 in
direct and diffuse reflection using the
formula:
C-Box/2A value = A*DQ1 + B*DQ2
Depicts the difference between both
distance values of the sensors 1/2 in
direct or diffuse reflection, in case of
one-sided distance measurement, and
outputs the result as height value.
Page 29
