4. Unmute the outputs: One at a time, press and hold the Output 3 button and then
the Output 4 buttons for approximately 2 seconds until each button lights steadily. The
output 3 and output 4 signals are unmuted.
Unmute outputs one at a time.
3
4
5. Exit View-only mode: Press and release the View button.
Press the button.
The View button returns to unlit
or background illumination.

Locking the Front Panel (Executive Mode)

The front panel security lockout limits the operation of the switcher from the front panel.
When the switcher is locked, all of the front panel functions are disabled except for the
View-only mode functions and deselecting the front panel Lock mode (see
Configuration
panel button when the switcher is locked, the View and Preset buttons flash twice and
return to their previous state.
To toggle the lock on and off, press and hold the Enter button and the Esc button
simultaneously for approximately two seconds (see figure 23).
Press and hold the Enter and
Esc buttons simultaneously to
toggle Executive mode on or off.
C O N T R O L
ENTER PRESET
Figure 23.
Press and hold the Output 3 button.
2 seconds
Press and hold the Output 4 button.
2 seconds
All input buttons and output buttons
VIEW
return to unlit or background illumination.
on page 26). Other than in View-only mode, if the user pushes a front
2 seconds
VIEW ESC ENTER
Locking the Front Panel
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Operation
The button returns to its previous indication
3
(lit, background illuminated, or unlit) to
indicate that the outputs are unmuted.
The button returns to its previous indication
4
(lit, background illuminated, or unlit) to
indicate that the outputs are unmuted.
The Preset and View
C O N T R O L
buttons blink twice
to indicate the mode
PRESET VIEW ESC
change.
Release the buttons.
Viewing a
34
