Introduction

AVERTISSEMENT : Risque potentiel de blessure grave ou de mort.
•
•
•

About this Guide

This guide contains installation, configuration, and operating information for the Extron
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 Matrix Switchers (see
next page). These customizable matrix switchers support DVI inputs and outputs and the
fiber optic outputs and inputs of Extron DFX transmitters and receivers. The switchers can
support multiple inputs and outputs, depending on the model:
•
•
•
•
NOTE: In this guide, "DMS matrix switcher" refers to any switcher model.

About the DMS Matrix Switchers

The DMS matrix switchers are configurable, modular matrix switchers that distribute a single
link of DVI (or HDMI with suitable adapters) digital video and DFX transmitter and receiver
outputs and inputs. The switchers are assembled from user-installed input and output (I/O)
boards. There are six I/O boards available:
•
•
•
WARNING: Potential risk of severe injury or death.
• The DMS outputs continuous invisible light (Class 1 rated), which may be harmful to
the eyes; use with caution.
• Le DMS émet une lumière invisible en continu (conforme à la classe 1) qui peut être
dangereux pour les yeux, à utiliser avec précaution.
• Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
•
ou dans les câbles fibre optique eux-mêmes.
Plug the attached dust caps into the optical transceivers when the fiber cable is
•
unplugged.
• Branchez les protections contre la poussière dans l'ensemble émetteur/récepteur
lorsque le câble fibre optique est débranché.
About this Guide
About the DMS Matrix Switchers
Features
DMS 1600 — up to 16 inputs and outputs
DMS 2000 — up to 20 inputs and outputs
DMS 3200 — up to 32 inputs and outputs
DMS 3600 — up to 36 inputs and outputs
4-input x 4-output DVI board
4-input DVI board
4-output DVI board
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Introduction
• 4-input x 4-output mutimode fiber optic board
• 4-input multimode fiber optic board
• 4-output multimode fiber optic board
figure 1
on the
1
