Operational flexibility — Operations such as input/output selection and setting of presets
can be performed using a variety of local and remote control mechanisms:
• Front panel controller
• Matrix Switchers Control Program
Simple Instruction Set (SIS)
•
• HTML pages
Remote control panels and keypads (see the list on
•
The serial ports allow remote control via a PC or a control system. The Ethernet link
allows multiple remote links with two levels of password protection.
NOTE: The DMS is shipped password-protected. The factory configured
passwords for all accounts on this device have been set to the device serial
number. In the event of a complete system reset, the passwords convert to the
default, which is no password (see
the password).
Upgradeable firmware — The firmware that controls all switcher operation can be
upgraded in the field via RS-232/RS-422 or Ethernet, without taking the switcher
out of service. Firmware upgrades are available for download on the Extron website,
www.extron.com, and can be installed using the Matrix Switchers Control Program or the
built-in HTML pages.
Labeling — The included Button Label Generator software lets you create labels to place in
the front panel I/O buttons, with names, alphanumeric characters, or color bitmaps for easy
and intuitive input and output selection. Alternatively, labels can be made with any Brother
P-Touch or comparable labeler.
®
Global memory presets — 32 global memory presets are available as a time-saving
feature that lets you set up and store input/output configurations in advance. You can then
recall those configurations, when needed, with a few simple steps. The presets are available
via front panel operation or serial port or Ethernet control.
Rack mountability — The DMS matrix switchers are housed in rack-mountable metal
enclosures with mounting flanges for standard 19-inch racks.
Front panel security lockout modes (Executive mode) — If a matrix switcher is
installed in an open area, where operation by unauthorized personnel may be a problem, a
security lockout mode can be implemented. When the front panel is locked, a special button
combination or SIS command is required to unlock the front panel controller and make the
front panel fully operational.
I/O grouping — Allows the matrix switcher to be virtually divided into smaller subswitchers,
making installation and control easier. I/O grouping limits the selection of inputs and outputs
to members of the same group. I/O grouping allows specific outputs, such as those
designated for a specific purpose, to be grouped together.
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Introduction
page 3)
Passwords Page
on page 92 to change
®
5
