Worksheet Example 3: Test Configuration

The video system in our fictional organization needs to be fine tuned on a regular basis.
Figure 30 shows a typical test configuration, with an Extron video test generator (input 12)
generating a test pattern to all projectors and monitors.
Camera Camera Podium Laptop
main #2 DVD
podium
1 2 3 4
1 2 3 4
Main Main Podium Conf.
hall hall monitor room
PJ#1 PJ#2
Preset # Title:
Fill in the preset number and use colors, or dashes, etc. to make connecting lines.
Figure 30.
Input sources
VCR Classrm Classrm PC1
(DVS 605) #1 DVD #2 DVD
5 6 7 8
5 6 7 8
VCR Lobby
(USP 507) monitor
Output destinations
Worksheet Example 3: Test Configuration
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Operation
Rack DVD VTG
(DVS)
9 10 11 12
9 10 11 12
Class Class Demo Demo
room #1 room #2 room rack
monitor monitor PJ#1 monitor
13 14 15 16
13 14 15 16
Demo
rack
switcher
