Using the Help System

For information about program features, you can access the help program in any of the
following ways:
•
•
•

Button Label Generator Program

The Button Label Generator software creates labels that you can place in the translucent
covers above and below the input and output buttons. You can create labels with names,
alphanumeric characters, or even color bitmaps for easy and intuitive input and output
selection (see
the procedure for removing and replacing the translucent covers).

Installing the Button Label Generator Software

The Extron Button Label Generator is available on the Extron website, www.extron.com, under the Download Cen-
ter tab. Click the
Software
1 1 1 1 1 1 1 1 1 1
Figure 54.
By default, the Windows installation creates a C:\Program Files\Extron\
ButtonLabelGenerator directory and places the Button Label Generator icon into a
group or folder named "Extron Electronics."
NOTE: For Windows 7 and newer, the folder is C:\Program Files (x86)\Extron\
From the Extron Electronics program folder or group, double-click on
the MATRIX Switcher Help icon (shown at right).
From within the Matrix Switchers Control Program, click the Help menu on
the main screen.
From within the Matrix Switchers Control Program, press the <F1> key.
Installing Labels in the Buttons of the Matrix Switcher
link (see figure 54, ), and download and install the program on your PC.
1
Location of Software on the Website
ButtonLabelGenerator.
DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Matrix Software
on page 106, for
83
