DXP 44 SDI &
DXP 88 SDI
SERIAL DIGITAL VIDEO MATRIX SWITCHERS
DXP 44 SDI
DXP 88 SDI
The Extron Digital XPoint Series of SDI digital matrix switchers is ideal for
switching multiple serial digital video signals to multiple digital video devices in
post production studios, non-linear editing suites, staging events, and video
broadcast studios.
MATRIX SWITCHERS
Serial digital data rates from 143
Mbps to 360 Mbps
SMPTE 259M compliant
Automatic input cable equalization
Digital Sync Validation Processing
(DSVP
™
)
Automatic rate selection
Output data muting when input
source is lost
16 global memory presets
LCD display
RS-232/422 remote control
Extron's Simple Instruction Set
(SIS
)
™
Windows
®
-based control program
www.extron.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Extron electronics DXP 88 SDI
Summary of Contents for Extron electronics DXP 88 SDI
- Page 1 DXP 44 SDI & DXP 88 SDI SERIAL DIGITAL VIDEO MATRIX SWITCHERS DXP 44 SDI DXP 88 SDI The Extron Digital XPoint Series of SDI digital matrix switchers is ideal for switching multiple serial digital video signals to multiple digital video devices in post production studios, non-linear editing suites, staging events, and video broadcast studios.
- Page 2 There are two models available in the Digital XPoint line: a four input by four output model (DXP 44 SDI) and a eight input by eight output model (DXP 88 SDI). Each input has an equalized and buffered loop- through, and each output has dual buffered and re-clocked BNC outputs.
-
Page 3: Video Input
SMPTE 259 M widescreen 16:9, component 4:2:2, and composite video) inputs, and 4 buffered loop-throughs DXP 88 SDI ... 8 SDI serial digital video (8 or 10 bit SMPTE 259 M widescreen 16:9, component 4:2:2, and composite video), and 8 buffered loop-throughs Connectors DXP 44 SDI ... - Page 4 DXP 44 SDI Back STATUS OUTPUTS 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 INPUTS DXP 88 SDI Front 1.5A MAX 100-240V 50-60Hz DXP 44 SDI Back Extron Electronics, USA 1230 South Lewis Street Anaheim, CA 92805 800.633.9876 714.491.1500...
