CSP 301 Digital signal processing unit with display for synchronous processing of 2 channels
Sensors, sensor cable, see Chap. 4.2, see Chap.
SWH
capaNCDT 6100
Appendix
Micrometer calibration fixture, range 0 - 2.5 mm, division 0.1 µm, for sensors CS05 to CS1
Digital micrometer calibration fixture, range 0 - 25 mm, adjustable offset, for all sensors
Power supply 24 V / 2.5 A; input 100 - 240 VAC, output 24 VDC / 2.5 A; Mounting on symmetri-
cal DIN rail 35 mm x 7.5 mm, DIN 50022; for max. 4 multifunction controller DT 3301
8-pin cable socket DIN 45326
Power- and output cable, 3 m (9.84 ft) long, 8-wire
Synchroniztion cable, 30 cm long
Vacuum feed through
34 (1.34)
2 (0.08)
max. 17
WS12
(.67)
4.3
