Installation and Assembly
4.3

Sensor Cable

The sensor is connected to the signal conditioning electronics by the sensor cable. The connection is made by simple plugging.
The connector locks automatically. The tight fit can be checked by pulling the connector housing (cable bushing). The lock can be
released and the connector can be opened by pulling the knurled housing sleeve of the cable bushing.
Sensor cable CCxC
8.6
(.34)
13.7
(.54)
17.5
(.69)
Cable length x
Sensor cable CCxB
Cable length x
Model 2 straight connectors 1x straight + 1 angled connector 90 °
CCxC •
CCxC/90
CC2B •
CC3B/90
capaNCDT 6100
27
(1.06)
37
(1.46)
27
(1.06)
37
(1.46)
•
•
x = 1 or 3 m
Bending radius:
10 mm min
i
Tension at the cable
is inadmissible!
Dimensions in mm
(inches), not to scale
for sensors
0.2 ... 0.5 mm
0.2 ... 0.5 mm
1 ... 10 mm
1 ... 10 mm
Sensor cable CCxC/90
16
(10.08)
Ø6
(.24 dia)
Ø5.4
(.21 dia.)
Sensor cable CCxB/90
25
(.98)
Ø7
(.28 dia.)
Ø10
(.39 dia.)
Page 49
