Installation and Assembly
PC3/8 is a 3 m (9.84 ft) long, pre-assembled 8-wire power and output cable. It is supplied as an accessory.
Pin assignment and color codes
PIN
1
6
2
4
5
3
7
8
capaNCDT 6100
Cable color
Assignment
white
0 Volt
green
+24 Volt
brown
+15 Volt
yellow
-15 Volt
grey
0 Volt
green
Output signal (distance) / voltage
blue
0 Volt
red
Output signal options
e.g. current 4 - 20 mA
black
Outer screen
bare
Inner screen (connect with Pin 7, blue)
24 VDC
Power
Outer cable
area with total
±15 VDC
screen
Power
(Option)
Inner cable,
3-wire with screen
Page 52
