Installation and Assembly
4.5
The power supply and signal output are connected by the 8-pin built-in connector (DlN 45326). Pin assign-
ment, see
ting cable.
PIN
1
2
3
4
5
6
7
8
Fig. 5
In addition the following applies:
- Outer screening mesh surrounds all cable wires.
- Inner screening mesh surrounds signal wires PIN 3, 7, 8.
- Inner screening mesh at pin 7.
- Total screen via connector housing to housing ground
- Recommended conductor cross-section 0.14 mm
The EMC regulations, see Chap. 1.3, are only satisfied under these basic conditions.
capaNCDT 6100

Power Supply and Signal Output

Fig. 5. The controller contains a 8-pin cable socket for the user-side assembly of your own connec-
Assignment
0 Volt (24 V operation)
+15 Volt (Option)
Output A displacement signal/voltage
-15 V (Option)
0 Volt (±15 V operation)
+24 Volt (24 V operation)
0 Volt (analog output)
Output B signal option (e.g. current)
Pin assignment
Use a double screened cable!
i
6 7
8
1
3
4
5
2
Solder pin side
cable socket
(AWG 26)
2
Requirements of-
power and output
cables to satisfy
the EMC regulati-
ons.
