IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>

13.1.10 Electrical connection

Voltage supply IN X31
Connector
Wiring
Ethernet IN / OUT X21, X22
Connector
Wiring
Process connection IO-Link Ports Class A X01...X0<IOL_AnzPorts>
Connector
Wiring
M12
1:
2:
3:
4:
M12
1:
2:
3:
4:
5:
M12
1:
2:
3:
4:
5:
+ 24 V DC (US)
-
GND (US)
-
TX +
RX +
TX -
RX -
-
+ 24 V DC (US)
DI
GND (US)
C/Q IO-Link
-
34608
49
