Read device and diagnostic information

In order to read the diagnostic information about the current device status via the web interface:
► Connect laptop/PC and AL1102 via the Ethernet internet.
► Start web browser.
► Enter the IP address of the AL1102 into the address field of the browser and press [ENTER] to confirm.
> Web browser shows the web interface of the device.
> The page shows the following data:
Table with connected IO-Link devices

Name
[Port]
[Mode]
[Comm. Mode]
[MasterCycleTime]
[Vendor ID]
[Device ID]
[Name]
[Serial]
[LR Mode / Interval]
 Diagnostic information of the device
Name
[SW-Version]
[Current]
[Voltage]
[Short Circuit]
[Overload]
[Undervoltage]
[Temperature]
Version information of the installed firmware components

Name
[Firmware]
[Container]
[Bootloader Version]
[Fieldbus Firmware]
22
Description
Number of the IO-Link interface
Operating mode of the IO-Link interface
Baud rate of the IO-Link interface
Cycle time
ID of the manufacturer of the IO-Link device
ID of the IO-Link device
Article number of the IO-Link device

For ifm articles: This article number is stored along with a link to the produkt page on
the ifm website.
Serial number of the IO-Link device
Cycle time for the communication with the SmartObserver
Description
Current (in mA)
Voltage (in mV)
Number of detected short circuits
Number of detected overloads
Number of detected under voltages
Device temperature (in °C)
Description
Firmware version
Version of the firmware container
Version of the boot loader
Version of the PROFINET firmware
