Communication, parameter setting, evaluation

Content
IO-Link ....................................................................................................................................................10
PROFINET..............................................................................................................................................10
Parameter setting ...................................................................................................................................10
Visual indication ......................................................................................................................................10
>
4.1.1 IO-Link
The device offers the following IO-Link functions:

IO-Link master (IO-Link revision 1.0 and 1.1)

8 IO-Link ports for connection of IO-Link devices

Provision of process data of the connected IO-Link devices for LR SMARTOBSERVER monitoring
software (→ www.ifm.com)
>
4.1.2 PROFINET
The device offers the following PROFINET functions:

Profinet RT Device (Class B)

2 port switch for access to the PROFINET interface; integrated switch is RT and IRT conform
according to PROFINET V2.3

Gateway for transmission of the process and parameter data between the connected IO-Link
devices and the higher-level PROFINET controller

Supported protocols: SNMP, LLDP, MRP, DCP, RTA, RTC Class 1 (nicht synchronisiert)

PROFINET features: FSU, I&M0 - 4 read/write

Device description: GSDML file
>
4.1.3 Parameter setting
The device provides the following configuration options:

Parameter setting of the IO-Link master of the AL1102 with parameter setting software LR
DEVICE and/or PROFINET projection software

Parameter setting of the connected IO-Link devices (sensors, actuators) with parameter setting
software LR DEVICE and/or PROFINET projection software

Storage of parameter sets of the connected IO-Link devices for automatic recovery (data storage)
>
4.1.4 Visual indication
The device has the following visual indicators:

Status and error indication of the gateway, of the PROFINET connection and of the system

Status display of the voltage supply

Status and activity display of the Ethernet connection

Status, error and short circuit/overload indication of the IO-Link ports
>
