13.2.3

Acyclic data

Content
I&M datasets ...........................................................................................................................................55
Diagnostic and alarms ............................................................................................................................57
>
I&M datasets
The AL1102 supports the following I&M datasets (I&M = Identification & Maintenance):
>
I&M0 (Slot 0)
Variable
Vendor ID
OrderID
Serial number
Hardware revision
Software revision prefix
Software Revision
Revision Counter
Profile ID
Profile Specific Type
IMVersion
IMSupported
* ... r = only read
>
I&M1 (Slot 0)
Variable
TagFunction of submodule
TagLocation of submodule
* ... r/w = read and write
>
I&M2 (Slot 0)
Variable
Installation_Date
* ... r/w = read and write
Description
IO-Link ID of the manufacturer
Order number of the device (numbers are separated by blanks)
Serial number of the device (numbers separated by blanks)
Hardware revision of the device
Prefix of the software revision of the device (V, R, P, U or T)
Software revision (numbers separated by blanks, e.g. x y z in "Vx.y.z")
Revision counter; is incremented with each parameter change
ID of sub-module profile (Slot 0: 0x0000)
additional value for profile ID; 0, if not used
I&M version (default value: 0x0101)
Suported I&M datasets (0x1110 for I&M1-3)
Description
function of the device (ASCII, padded with spaces)
Location of the device in the plant (ASCII, padded with spaces)
Description
Installation date of the device (ASCII, padded with spaces)
reserved
33868
34555
34545
Access* Size
r 2
r 20
r 16
r 2
r 1
r 3
r 2
r 2
r 2
r 2
r 2
34543
Access* Size
r/w 32
r/w 22
34544
Access* Size
r/w 16
r/w 38
