IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>
9.1.6

IO-Link ports: Configure operating mode

The IO-Link ports X01...X08 of the device support the following operating modes:

Digital input (DI): binary input signal at pin 4 (C/Q) of the IO-Link port

Digital output (DO): binary output signal at pin 4 (C/Q) of the IO-Link port

IO-Link: IO-Link data transfer via pin 4 (C/Q) of the IO-Link port
The user can set the operating mode separately for each IO-Link port.
To set the operating mode of an IO-Link port:
► Select [Port x] menu (x = 1...8).
> The menu page shows the current settings.
► Set the following parameters as required:
Name Description
[Mode] Operating mode of the IO-Link port
[Cycle time actual]** Current cycle time of the data transfer between
IO-Link master and IO-Link device on the port
(value in microseconds)
[Cycle time preset]* Cycle time of the data transfer between the IO-Link
master and the IO-Link device at the port (value in
microseconds)
[Bitrate]** Current transmission rate of the data transfer
between the IO-Link master and the IO-Link device
on the port
* ... Parameter only available if [Mode] = [IO-Link]
** ... Parameter only visible if the IO-Link device is connected to the IO-Link port.
► Save changed values on the device.
Possible values
[Disabled] Port deactivated
[DI] Operation as digital input
[DO] Operation as digital output
[IO-Link] Operation as IO-Link interface
Parameter can only be read
0 The device automatically sets
the fastest possible cycle time.
1 1 microsecond
... ...
132800 132800 microseconds
Parameter can only be read
