IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>
13.2

PROFINET

Content
Parameter data .......................................................................................................................................50
Cyclic data ..............................................................................................................................................53
Acyclic data ............................................................................................................................................55
>
13.2.1 Parameter data
Slot Subslot Name
1 1 Master
2 Port X01
3 Port X02
4 Port X03
5 Port X04
6 Port X05
7 Port X06
8 Port X07
9 Port X08
>
Parameter of the IO-Link master
Parameter Description
[Access Rights] The access rights to the
parameter data, process data and
events/diagnostic messages of
the IO-Link master and the
connected IO-Link devices
>
50
Description
Parameter data of the IO-Link master (→

Parameter data of the IO-Link ports (→

modules (→ PROFINET modules
Possible values
PROFINET + IoT
PROFINET + IoT (ro)
PROFINET only
keep setting
Parameter of the IO-Link master
Parameters of the IO-Link ports
(→ S. 53))

PROFINET and LR DEVICE have read
and write access rights to parameters
and process data

PROFINET and LR DEVICE have read
access rights to events/alarms

PROFINET has read and write access
rights to parameters and process data

PROFINET has read access rights to
events/alarms

LR DEVICE only has read access
rights to parameters, process data and
events/alarms

PROFINET has read and write access
rights to parameters and process data

PROFINET has read access rights to
events/alarms

LR DEVICE has no access rights
(parameters, process data,
events/alarms, web interface, firmware
update)
keeps settings
33674
34546
(→ S. 50))
(→ S. 51)
34552
