IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>
9.1.7

IO-Link ports: Set the device validation and data storage

In the operating mode "IO-Link" the user can set the behaviour of the IO-Link port with regard to
device validation and the storage / restoration of the parameter data of the connected IO-Link device.
To configure the device validation and the data storage:
► Select [Port x] menu (x = 1...8).
> The menu page shows the current settings.
► Set the following parameters as required:
Name Description
[Validation / Data Supported IO-Link standard and
Storage] behaviour of the device during
connection of a new IO-Link
device on port x (x = 1...8)
[Vendor ID] ID of the manufacturer that is to
be validated
[Device ID] ID of the IO-Link device that is to
be validated
► Save changed values on the device.
>
30
Possible values

[No check and No verification of the vendor ID and device
clear] ID

No data storage

[Type IO-Link device is compatible with the V1.0
compatible IO-Link standard
V1.0 device]

Verification whether it is an IO-Link device of
the same type (validation via vendor ID and
device ID)

No data storage

[Type IO-Link device is compatible with the V1.1
compatible IO-Link standard
V1.1 device]

Verification whether it is an IO-Link device of
the same type (validation via vendor ID and
device ID)

No data storage

[Type IO-Link device is compatible with the V1.1
compatible IO-Link standard
V1.1 device

Verification whether it is an IO-Link device of
with Backup +
the same type (validation via vendor ID and
Restore]
device ID)

The IO-Link master saves the parameter
values of the connected IO-Link device;
modifications of the parameter values are
also saved (observe the note!)

When connecting an IO-Link device with
factory settings, the parameter values stored
in the IO-Link master are restored
automatically on the IO-Link device.

[Type IO-Link device is compatible with the V1.1
compatible IO-Link standard
V1.1 device

Verification whether it is an IO-Link device of
with Restore]
the same type (validation via vendor ID and
device ID)

The IO-Link master saves the parameter
values of the connected IO-Link device
once.

When connecting an IO-Link device with
factory settings, the parameter values stored
in the IO-Link master are restored
automatically on the IO-Link device.
0 Factory setting: 0
...
ifm electronic: 310
65535
0 Factory setting: 0
...
16777215
