IO-Link Master with PROFINET Interface StandardLine 8 Ports IP 65 / IP 66 / IP 67
>
9.2.4

Configure IO-Link ports

You can access the configuration of the IO-Link ports via the slots 1.2 ... 1.9 of the AL1102. The
following assignment applies
Slot
1.2
1.3
...
1.9
The available PROFINET modules are defined in the GSD file (→
PROFINET module determines the following properties of an IO-Link port:

Operating mode (IO-Link, DI, DO, deactivated)

Type and length of the process data

optional data (fail-safe values, device validation, data storage, cycle time, events)
The following table shows the available parameters depending on the selected operating mode:
Operating mode of the IO-Link
ports
DI: digital input
DO: digital output
IO-Link: input
IO-Link: output
IO-Link: input and output
-- = not available
X = available
To configure an IO-Link port of the AL1102:
► Drag the required PROFINET module from the hardware catalogue and drop it on the slot of the IO-Link port.
► Double click on the slot of the IO-Link port
► Set the parameters as required (→
► Repeat the steps to configure further IO-Link ports.
► Save the project.
36
IO-Link port of the AL1102
Port X01
Port X02
...
Port X08
Fail-safe Pattern Validation /
mode Value
-- --
X --
-- --
X X
X X
Parameters of the IO-Link ports
PROFINET modules
Available parameters
Vendor Device ID
Data ID (VID)
storage
-- --
-- --
X X
X X
X X
(→ S. 51)).
(→ S. 53)). A
Port cycle IO-Link
time events
-- -- X
-- -- X
X X X
X X X
X X X
