1.6

Type plate

Each nursing care bed is marked with an individual type plate. Either there is only one
sticker on your nursing care bed (Fig. 1, previous nursing care bed models) or there are
two separate type plates (Fig. 2, current nursing care bed models) on your nursing care
bed.
Type plate for previous nursing care bed models
(1) Model designation
(2) Manufacture date: Day, month and year
(3) Serial number: Order number - running number
(4) Mains voltage, mains frequency and power input
(5) Duty cycle
(6) Drive protection class
(7) Maximum patient weight / safe working load
(8) Manufacturer
(9) Symbols (located on the right side)
Conformity mark according to the medical device directive
IPX4
Protection of electrical equipment against splashing water
Medical application part type B
Use only in dry rooms
Protection class II (double insulation, insulated for protection)
Within the European Union, this product must be disposed via the
separated municipal waste. Product may not be disposed
of as household waste.
Symbol for maximum patient weight
Symbol for safe working load
Symbol for observance of the user manual
