BOCK belluno Assembly And Operation Manual page 53

Inspection list for Bock nursing care beds
Name / location:
Address / Postcode / City:
Station / Room:
Name of examiner / Date:
Functional testing:
No. Description
Side rail:
Are the side rails running smoothly in the tracks and locking into place
safely?
21
Only nursing care bed dino: Smooth running of the doors on the aluminium
profiles? Doors lock securely into the locking mechanism?
Are the side guard rails/parts sufficiently mounted and firmly seated?
22
Was the load stress test of the side rail without deformation?
23
Lying surface:
Back part, leg part adjustment and special functions properly and without
24
any obstacles?
Safe grid mechanism of lower leg rest (if available) in every step, even under stress?
25
Only domiflex 2 nursing care bed: Is the clamping effect of the 6 eccentric clamps suf-
26
ficient? If this is not the case, the stop nut must be tightened slightly!
Chassis (with scissors construction beds) / end panels (of actuator beds):
Hub adjustment properly and without any obstacles?
27
Safe braking effect, blocking and free running of wheels?
28
Electric components:
Testing of hand control (keys and disabling function) all working properly
29
without any defects?
Battery/Bock battery/emergency lowering: Function properly and without any de-
30
fects?
General:
Function of the accessories flawless and safe? (e.g. lifting pole incl. grab han-
31
dle and belt, stand-up aids, wall deflector holder, etc.)
Electric measuring:
No. Description
Insulation resistance -
(must be only measured on old models before manufacture year of 2002.)
Insulation resistance – measured value larger than 7 MΩ?
32
Device leakage current - (This measurement does not have to be carried out for nursing care beds with a limoss drive set for
nursing care beds manufactured from 2018-05 onwards, or for nursing care beds with a Dewert drive set for nursing care beds
manufactured from 2015-07 onwards during the first 10 years of service life, if the visual and functional testing is passed, if this
is a nursing care bed with a limoss or Dewert switched-mode power supply (SMPS). With these nursing care beds, the mains
voltage is directly converted into a safety extra-low voltage of max. 35 V in the switch-mode power supply unit.)
Device leakage current - measured value smaller than 0.1mA?
33
Evaluation
No. Description
All values/inspection within the permissible range passed?
34
In the event the inspection result did not pass:
Date / Signature
Page 2 of 2
53
Issuing date: 09.10.2018
Yes No Remark
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
☐ ☐
Yes No Remark
☐ ☐
☐ ☐
Yes No Remark
☐ ☐
☐Repair
☐Singling out
Next inspection
