are marked with corresponding symbols. The servomotors run until as long as a corre-
sponding key is pressed and held. A coiled cable allows the necessary freedom of move-
ment while operating.
With the rear-mounted suspension unit, the hand control can be attached to the side rail
- particularly when cleaning and during the maintenance of the bed. Thus, a possible dis-
ruptive position of the hand control can be avoided by simply attaching it to any preferred
spot on the bed.
* availability depends on the model
** Comfort sitting position only moves up. All adjusted positions must be lowered separately.
Do not exceed the maximum duty cycle of 2 minutes. Observe a subsequent break of at least
18 minutes by all means.
Back part upwards
Back part downwards
Lower leg part upwards
Lower leg part downwards
Auto contour upwards *
Auto contour downwards *
Lying surface upwards
Lying surface downwards
Low foot support (Anti Trendelenburg) *
Head-lowering position (Trendelenburg)
*
Comfort sitting position * (upwards only
**)
Enable low function *
Reset *
Lighting on/off *
Hazard note by Bock
22
Examples for different
hand controls
