  • Page 1 Assembly and operation manual combiflex fc...
  • Page 2 Dear Customer, In deciding to buy our comfort sleep system combiflex fc you have opted for a first class product in functionality and reliability. This product has been manufactured and tested in accordance with the current valid standards for medical used beds.

  • Page 3: Table Of Contents

    6.2 Special features 6.3 Scope of delivery 6.4 Technical Data 6.5 Assembly of the combiflex fc bed-in-bed system 6.6 Changing of the bed-in-bed system to a comfort bed 6.7. The assembly of the telescopic splitted side rails and side paneling of the frame 6.8 Disposal...

  • Page 4: General Notes

    1. General notes * Warning note from Bock The user of this product is The various bed systems that are made by Hermann Bock GmbH highly recommended to meet the special requirements for use in rehabilitation and the- thoroughly read this assem- rapy establishments as well as for care at home.
  • Page 5 – Do never open the box or the plug of the motor! Due to unauthorised opening and inappropriate repairs the warranty claim expires. Furthermore, risks for the user might occur. – Repairs can only be carried out by specialized person- nel! –...

  • Page 6: Cleaning, Care And Disinfection

    2. Cleaning, care and disinfection > Bock top advice Scrapes and varnish chip- The individual bed elements are made up of high-quality mate- pings that go through rials. The surfaces are covered with a permanent polyester-coa- the entire varnish coating ting.

  • Page 7: Disinfection

    The ripolux support system: To clean the plastic carrier and spring elements as well as the base use a slightly moistened cloth without adding any cleaner, or add a product that has been designed specifically for plastics. If the support system needs particularly intensive cleaning, pull off the spring elements and the carrier elements off the lying surface frame.

  • Page 8: Avoid Hazards

    2.3 Avoid hazards * Warning note from Bock Please make sure to consider the following guidelines with It is absolutely not recom- respect to the electrical component parts of your nursing beds mended to use abrasive as this crucial to avoiding hazards related to the cleaning and dis- cleansers resp.

  • Page 9: General Description Of Function

    Lower leg support 3. General description of function 3.1. Constructive design and function The lying surface Besides a robust slatted frame, the lying surface of the Bock health bed can be optionally equipped with two further lying surface variants. The combi-lying surface...

  • Page 10: How To Carry Out The Quick And Easy Assembly

    The lifter The height adjustment of the comfort bed combiflex fc is carried out by a double lifter technique. The double lifter can be height adjusted by two integrated single motors. The surface of...
  • Page 11 The splitted telescopic side rails > Bock top advice As an option the comfort bed combiflex fc can be equipped with Should the side rail form splitted side rails. The side rails serve as a protection against fal- the diagonal position ling out and makes the getting in and out of the bed easy.
  • Page 12 In order to lower the other part of the side rail, please grab the side rail on the part of the end panel. Push the locking device on the end panel (Fig.4) and lower it slowly. Now the side rail is in the lowered position (Fig.

  • Page 13: Caution: Personal Injuries

    3.3 Caution: Personal injuries * Bock-Gefahren-Hinweis The intended use of all moveable component parts is likewise During the electrical crucial for the prevention of hazards to the person in need of adjustment of the lying care as for the safety of the relatives and/or nursing staff. This...
  • Page 14 The distances between the side railings have to be less or equal > Bock top advice 12 cm. Note that the side railings must not remain in diagonal position, when these are being used. When using different mat- tress thicknesses, the mini-...
  • Page 15 * Warning note from Bock – Do only use original side railings from Bock which are available as equip- ment for every nursing bed. – Do only use technically sound and undamaged side railings that have the permissible clea- rances.

  • Page 16: The Ics Sytem

    4. The ICS System 4.1 What is ICS? The ICS is an entirely new solution for manufacturers of medi- cal, healthcare, and wellness/ therapy beds. Intelligent control systems (ICS) are able to control and monitor components and parameters of a medical product in the most dependable man- ner.
  • Page 17 The hand set of the combiflex fc The following function can be controlled by pushing the buttons: Function button 1 Back rest up Function button 2 Back rest down Function button 3 Lower leg part up Function button 4 Lower leg part down...

  • Page 18: Analysis Function Of The Handset

    4.3 Analysis function of the handset Red LED is flashing twice (2x) Actuator is overloaded (Power cut-off). This failure mode is due to • Bed load is higher than the safety load parameters • Bed collides with something (pinching protection) Red LED is flashing four times (4x) Hall impulses are missing.
  • Page 19 * Warning note from Bock 4.4 Attention: Electronic drive Hermann Bock calls its electrically operated nursing and therapy The high safety standard beds health beds, because they considerably facilitate the care of Hermann Bock´s beds recipient‘s recovery process in both physical and mental aspects...

  • Page 20: The Mains Isolation

    4.5 Mains isolation * Warning note from Bock The mains isolation facility that is integrated in the mains plug The simultaneous use of provides other practical advantages in addition to guaranteeing electrical devices may cau- a high level of safety. Activation of mains isolation prevents...

  • Page 21: Accessories

    5. Accessories 5.1. Accessories In case that the combiflex fc should be used as a nursing care bed, Hermann Bock offers practical and supporting accessories. Please have a look at our web site www.bock.net. 5.2. Mattresses We at bock consistently implement the requirement of “lying healthily”.
  • Page 22 Do you have a bed with wooden slats but do not want to miss the * Warning note from Bock modern spiroplex spring technology? That is why bock developed ® For safety reasons just use ripomed II: the mattress with integrated spiroplex spring system.

  • Page 23: Special Features

    Bed- in-bed-system comfort bed Sleep is individual- and so is combiflex fc. Design your individual sleep system. The combiflex fc grows with your requirements, even later adjustments are possible without a problem. Equip the comfort system individually with the combiflex fc...

  • Page 24: Technical Data

    The following components are included in the delivery of Bock‘s combiflex nursing bed: Separable lying surface with case motor 3 items Separable base frame with lift motors 2 items Guide rollers 1 set (4 items) Head- resp. foot part...
  • Page 25 6.5 The combiflex fc bed-in-bed system gets ready for use Fig. 1 Make sure that you have removed the complete packaging before you continue with the next assembly steps. 1. Remove the ties from the transport packaging 2. Place the both parts of the base frame on the floor (Fig.
  • Page 26 Fig. 6 Fig. 3, right Fig. 4 6. Plug the both halves of the lying surface and fasten them using the screws provided. 7. Hook the case motor up to the drive screws of the lying surface (Fig. 6). Fix the case motor using the locking slides on both sides (Fig.
  • Page 27 Fig. 7 8. Take the lying surface and connect it with the base fra- me in such a way, that the ball bearings at the upper area of the base frame can be inserted exactly into the U-profile at the bottom side of the lying surface (Fig. 8). Fig.
  • Page 28 10. If the combiflex bed insert should be integrated into a bedframe, pull off the side leaves until the bed frame width is being reached (Fig. 11, max. 10 cm) and fix them at the bed frame (Fig. 12). 11. Connect the plugs at the wire-end of the base frame‘s lift motors into the appropriate jacks at the case motor.
  • Page 29 6.6 The retrofitting of the bed-in-bed system to a comfort bed The retrofitting of the combiflex fc bed-in-bed system to a com- fort bed is carried out by the assembling of the castors or alumi- num feet, the end panels and the wooden side rails.

  • Page 30: Paneling Of The Frame

    Fig. 1, Fig. 2, 6.7 Assembly of the telescopic splitted side rails and the side panelling of the frame: – On the head end: The U-profile of the telescopic bar has to be mounted on the frame of the lying surface (pic- ture 1).
  • Page 31 The adjusta- ble range has to be without obstacles. The net cable has to be outside the bed and the hand set has to be accessible. Combiflex fc is now ready for use!

  • Page 32: Disposal

    6.8 Disposal * Warning note from Bock The single material components made of aluminium, plastic, Never try to fix problems metal and wood are recyclable and can be re-used correspondi- relating to electric equip- ng to the legal determination. Litter that occurs due to repair and...
  • Page 36 Hermann Bock GmbH Nickelstr. 12 33415 Verl Germany Phone: +49 (0) 52 46 92 05 - 0 Fax: +49 (0) 52 46 92 05 - 25 Internet: www.bock.net E-Mail: info@bock.net ® registered trademark 890.01981 | 08.2012 Technical alterations reserved.
