BOCK belluno Assembly And Operation Manual page 16

All dimensions in mm.
* Depending on the length of the lying surface
The single post at the head and leg end is optional.
The dimension in brackets is optional
Area Description
A Distance between the head part and the side rail
B Height 1 of side rail
C Height 2 of side rail
D Width 1 of the side rail
E Distance between the elements within the
Side rail
F Distance between the divided side rails
G Distance between the lying surface and the upper edge of
the side rail
H Height of the top edge of the side rail above the
mattress without compression
I Thickness of the mattress for the intended
use
J Width 2 of the side rail
K Smallest dimension between side rail and
lying surface (or the panel, if any)
L Distance between the foot part and the side rail
Use only original Bock side rails, which are available as accessories for every nursing care beds.
Use only technically flawless and non-damaged side rails with the permissible gap dimensions.
Make sure that the side rails are engaged securely.
Before installation of the side rail and each new use, inspect all mechanical parts on the bed
frame, and all parts of the side rails, and all parts which secure the side rails, for any possible
damages.
The operation of the side rail should be done with great care. Fingers can be quickly pinched
between the longitudinal pieces.
Legend
Hazard note by Bock
Description
Item numbers
Designation
Continuous wood / steel side rail
Two-part (Fig. 1)
Wood side rail (set: 95 / 95mm)
Wood side rail (set: 95 / 110mm)
Steel side rail (set: 95 / 110mm)
Three-part (Fig. 2)
Wood side rail (set: 95 / 95mm)
Wood side rail (set: 95 / 110mm)
Duo-post central (Fig. 3)
Duo post
Wood side rail (set: 95 / 95m)
Wood side rail foot (set: 95 / 95m)
Solo-post central (Fig. 4)
Solo post (head right, foot left)
Solo post (head left, foot right)
Wood side rail (set: 95 / 95mm)
Posts at head and foot part (without Fig.)
Solo post (head right, foot left)
Solo post (head left, foot right)
Wood side rail continues (set: 95 / 95mm)
16
Telescopic wooden side rail
Item no.
90223
91247
91314
91566
91531
91210
80344
80345
91211
91212
80346
91211
91212
80346
