Immunity test
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrical fast
transient/burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
NOTE 1: U
070-1149-01 B
Electromagnetic Immunity
IEC 60601
test level
±6 kV contact
±8 kV air
±2 kV for power
supply lines
±1 kV for
input/output lines
±1kv differential
mode
±2 kV common
mode
<5% U
T
(<95% dip in U
for 0,5 cycle
40% U
T
(60% dip in U
T
for 5 cycles
70% U
T
(30% dip in U
T
for 25 cycle
<5% U
T
(<95% dip in U
for 5 sec
3 A/m
is the a.c. mains voltage prior to application of the test level.
T
Compliance Electromagnetic environment -
level guidance
±6 kV contact Floors should be wood, concrete or ceramic tile.
If floors are covered with synthetic material, the
±8 kV air
relative humidity should be at least 30%.
±2 kV for power Mains power quality should be that of a typical
supply lines commercial or hospital environment.
±1 kV for
input/output lines
±1kv differential Mains power quality should be that of a typical
mode commercial or hospital environment.
±2 kV common
mode
<5% U Mains power quality should be that of a typical
T
commercial or hospital environment. If the
) (<95% dip in U )
T T
Eclipse Premier user requires continued
for 0,5 cycle
operation during power mains interruptions, then
40% U
T
it is recommended that the Eclipse Premier be
) (60% dip in U )
powered from an uninterruptible power supply or
T
for 5 cycles
a battery.
70% U
T
) (30% dip in U )
T
for 25 cycle
<5% U
T
) (<95% dip in U )
T T
for 5 sec
3 A/m Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.

EMC Declaration Tables

Eclipse Operating Instructions
11-7
