Chapter 3
Keyboard and Displays

The PREVIEW Screen

Figure 3-2
The Preview Screen
3-4
Eclipse Operating Instructions
After the Eclipse Premier has been turned on and performs self-tests, the PREVIEW
screen is displayed (see Figure 3-2). General features are described below.
A
I D : 0 1 2 3 4 5 6 7 8 9
J O N E S , T H O M A S
I
aVR
II
aVL
I
III
aVF
II
R A L A
(A) PATIENT ID
Identification number of the current patient. On the Eclipse Premier, this field also
displays the patient's name.
(B) RELATIVE GAIN
Tracks the amplitudes of the displayed waveforms. This corresponds to the Recorder
Gain setting as follows:
Recorder Gain
5 mm/mV
10 mm/mV
20 mm/mV
L=10, C=5 mm/mV
L=20, C=10 mm/mV
(C) HEART RATE
Displays the patient's heart rate.
V1
V2
V3
SENSORS OK
L L V 1 V 2 V 3 V 4
H
Relative Gain
L=x1, C=x1/2
B C
65
P R E S S
L=x2,C=x1
I
ECG
M
V4
Available:60 ECG
V5
V6
U s e r : 1
2 5 m m / s
L 2 0 , C 1 0 m m / m V
STABLE 40 Hz
V 5 V 6
AC ON
G
x1/2
x1
x2
L=x2, C=x1
ENTER ID
D
RECORD
MAIN MENU
E
+
F
070-1149-01 B
