Chapter 4
System Setup and User Setup
Barcode Scanner
4-4
Eclipse Operating Instructions
Connection MODEM
DIRECT
802.11b/802.3
NONE
Determines what type of connection is used when sending or
receiving records. Selecting NONE disables any sending or receiving
functions on the Eclipse Premier. This will also allow the Eclipse
Premier to automatically delete records that do not have the St status
(see "Record Status" on pg. 7-2).
Baud Rate 2400
AUTO
Determines the rate at which the modem will send or receive records.
Selecting AUTO allows the modem to send or receive records at the
fastest rate depending on the speed of the modem on the connecting
equipment.
AC Mains UNSPECIFIED
50 Hz
Frequency
60 Hz
Labels ECG records with the frequency of the AC line power which is
connected to the Eclipse Premier unit. This is used by the PYRAMIS
System to identify the line frequency in the area where the records
are acquired.
Paper Type ASSURANCE 50
STANDARD
Sets print head resistance according to paper type selected.
Analysis BRIEF
Statements FULL
Selects the format of the ECG analysis statements. Selecting BRIEF
will result in short, concise analysis statements with minimal
explanations, presented in mixed case nomenclature for ease of
reading (for example, "Normal ECG"). Selecting FULL results in
lengthier analysis statements—presented in upper case
nomenclature (for example, "NORMAL ECG")— and reason
statements, which precede the analysis statements.
ON
OFF
Enables or disables barcode scanning. When the barcode scanner
has been installed and enabled, patient demographics can be
entered by scanning one or more barcodes.
070-1149-01 B
