4
Chapter

Configuring SYSTEM SETUP Menu

Figure 4-1
The SYSTEM SETUP Menu
070-1149-01 B

System Setup and User Setup

Within the SYSTEM SETUP menu you can select User 1 or User 2, format Eclipse
Premier general settings, and set the internal calendar & clock. Setting options are
listed in "SYSTEM SETUP Fields" on pg. 4-2.
NOTE: Default settings for Eclipse Premier are given on page 9-2.
Go to SYSTEM SETUP menu
1. Press the On/Standby key to power up to the PREVIEW screen.
2. Press the "M" key to go to the MAIN MENU.
3. Select SYSTEM SETUP by pressing the "S" key. The SYSTEM
SETUP menu will appear (see Figure 4-1).
ID:0123456789
U s e r 1 - 2 S e l e c t :
L i n e F i l t e r : 6 0 H z
D a t e F o r m a t : D D . M M . Y Y
D a t e : 1 2 . 1 1 . 1 9 9 5
T i m e : 1 3 : 4 5
L a n g u a g e : E N G L I S H
H e i g h t U n i t s : I N .
W e i g h t U n i t s : L B .
I n s t . N a m e :
4. Use the up and down arrow keys to scroll through the fields in the
SYSTEM SETUP menu. As you scroll through the fields, the options
available for each field will be displayed when the field is highlighted.
5. Once a field is highlighted, change the current selection by pressing
the hot key associated with the option. For example, to select User 1 in
the User 1-2 Select field, press the "1" key.
6. Use the keyboard to enter information into fields with a blinking
cursor, such as Inst. Name.
Use the left arrow key to exit the menu.
65 PRESS
x1
MAIN MENU
SYSTEM SETUP
1
USER
1
2
Eclipse Operating Instructions
4-1
