Chapter 8
Sending and Receiving Records

Setting Up the Unit to Send and Receive

8-4
Eclipse Operating Instructions
Mark Record As "DO NOT SEND"
To ensure that a record is not sent the next time BATCH SEND ECGS is selected, select
the MARK RECORD AS "DO NOT SEND" from the Single ECG Functions list.
1. Follow the instructions for accessing the list of patient files (see
"Using the DIRECTORY Menu" on pg. 7-1).
2. Locate the desired patient file, highlight it and press the Enter key. The
Single ECG Functions list is displayed.
3. Select MARK RECORD AS "DO NOT SEND" from the Single ECG
Functions list
4. The record is marked with the No status. The file will not be sent the
next time BATCH SEND ECGS is selected.
The Eclipse Premier can transmit and receive records in three ways:
Direct Connection
●
Wireless Connection (optional)
●
Remote Connection
●
A direct connection is achieved through the use of a cable, which connects the Eclipse
Premier unit to either PYRAMIS or another Eclipse unit. A wireless connection is
achieved through a wireless transmitter attached to the Eclipse Premier, a wireless
access port, and receiver software. A remote connection requires either an internal or
external modem connected to a phone line.
Using a Direct Connection
1. If you are connecting to PYRAMIS, connect the Interconnect Cable to
the connector labeled "DECG-SCP" on the PYRAMIS back panel and
to the connector labeled "IOIO" on the Eclipse Premier back panel.
2. If you are connecting to another electrocardiograph, connect the
Eclipse Direct Connect Cable #007796 to the connectors labeled
"IOIO" on the back panel of each Eclipse.
NOTE: Follow steps 3 through 8 on both Eclipse units.
3. Press the On/Standby key to power up to the PREVIEW screen.
4. Press the "M" key to go to the MAIN MENU.
070-1149-01 B
