Custom Lead 1
070-1149-01 B
CUSTOM LEAD 1 & CUSTOM LEAD 2
These two menus each format a group of leads. These groups can later be selected by
pressing the "5" or "6" machine control keys (see "The Keyboard" on pg. 3-1).
Custom Lead Group 1 is also used for the rhythm page of an Auto ECG report. Only
Standard or Cabrera configurations are acceptable for this purpose. Do not select Frank
or Nehb if you want a rhythm page as part of an Auto ECG.
NOTICE: Because the Eclipse Premier offers different lead configurations, always
ensure that the appropriate lead placement is employed for the lead configuration
selected.
STANDARD, 3 CHANNEL (3x1)
STANDARD, 6 CHANNEL (6x1)
STANDARD, 12 CHANNEL (3x4)
STANDARD, 12 CHANNEL (3x4, 1R)
STANDARD, 12 CHANNEL (3x4, 3R)
STANDARD, 12 CHANNEL (6x2)
CABRERA, 3 CHANNEL (3x1)
CABRERA, 6 CHANNEL (6x1)
CABRERA, 12 CHANNEL (3x4)
CABRERA, 12 CHANNEL (3x4, 1R)
CABRERA, 12 CHANNEL (3x4, 3R)
CABRERA, 12 CHANNEL (6x2)
ALTERNATE CHEST LEAD (3X4, 1R)
FRANK, 3 CHANNEL (3x1)
NEHB, 3 CHANNEL (3x1)
Format Custom Lead 1 to suit your needs. The numbers in parentheses indicate how
the selected lead group will be displayed on the screen. If you select a display that
includes rhythm leads, the rhythm leads displayed are the same ones that have
been selected for printing in the Auto ECG Setup menu. (See "AUTO ECG SETUP"
on pg. 4-9.)
If you have selected Alternate Chest Lead or a non-12 lead Standard or Cabrera
format, select leads for the appropriate channels. Lead availability is affected by the
selected lead configuration.
