70-00582-01 A
Instruction Manual
Cardiac Science 5300 and
Cardiac Science 5350
Vital Signs Monitor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cardiac Science 5300

Summary of Contents for Cardiac Science 5300

  • Page 1 70-00582-01 A Instruction Manual Cardiac Science 5300 and Cardiac Science 5350 Vital Signs Monitor...
  • Page 2 ANUAL 70-00582-01 A Important: Be sure to fully read this manual before using the Cardiac Science 5300 and 5350 Vital Signs Monitor to ensure correct and safe use. After you have read this manual, store it near the monitor so that it can be used for reference.
  • Page 3 Information in this document is subject to change without notice. Names and data used in the examples are fictitious unless otherwise noted. Trademark Information Cardiac Science, the Shielded Heart logo, Quinton, Burdick, and HeartCentrix are trademarks of Cardiac Science Corporation. OMRON® is a registered trademark of OMRON CORPORATION.

  • Page 4: Table Of Contents

    Warnings and cautions ................1-5 Safety alert descriptions..............1-5 General warnings and cautions ............1-5 Installation..................1-7 NIBP ....................1-8 ....................1-9 Temperature ..................1-10 Alarm (Cardiac Science 5350 only) ............1-10 Internal Battery................1-11 Maintenance..................1-11 Other labels ...................1-12 Symbols and labels ................1-13 Chapter 2: Outline Configured products ................2-2 Main unit ..................2-2 Names and functions of parts ..............2-6...
  • Page 5 Elapsed time ..................4-19 Smart Inflation™ ................4-19 High speed measurement (default setting is OFF)......4-21 BP silent mode................4-22 Blood pressure measurement end sound.........4-24 After measurement ................4-25 Cuff measurement interval OFF (Cardiac Science 5350 only) ............4-25 Clear display (Cardiac Science 5300 only) ............4-27 Contents...
  • Page 6 Delete list screen ................7-4 Exiting the setting screen ..............7-4 Exiting list display ..................7-5 Chapter 8: Alarms Alarm settings (Cardiac Science 5350 only)...............8-2 About setting mode .................8-2 Alarm setting screens ...............8-2 Changing the alarm setting value .............8-3 Entering the alarm setting value............8-3 Exiting the setting screen ..............8-3...
  • Page 7 Contents Recovering from an alarm ..............8-5 Extinguishing an alarm ..............8-5 Alarm setting range ................8-6 Chapter 9: Recorder Preparations before use ................9-2 Setting up the roll paper ..............9-2 Manual recording ...................9-3 List types..................9-3 Simple list recording (LST 1)............9-4 Detailed list recording (LST 2) ............9-5 Measurement value recording (OSCL)..........9-6 All list recording ................9-6 List record pattern selection .............9-7...
  • Page 8 Contents Operating time..................11-4 Battery and ambient temperature ............11-4 Warranty....................11-4 Appendix A Error code table..................A-2 System error code table ..............A-2 Non-Invasive Blood Pressure (NIBP) measurement section error code list ..........A-4 error code table ..............A-10 Body temperature error code table ..........A-12 Principles ....................
  • Page 9 Contents Pulse oximeter (models with Nellcor® SpO ) ........ A-38 Pulse oximeter (models with Masimo® SpO ) ....... A-40 E-Temp ..................A-42 FCC STATEMENT..............A-43 Manufacturer’s declaration............A-44 viii Contents...
  • Page 10 Symbols and labels 1-13 ◆ Thank you very much for choosing a Cardiac Science 5300 or 5350 vital signs monitor. This chapter contains important safety and care information. Cardiac Science provides customer service and technical support. To order additional product or accessories, contact Customer Care.

  • Page 11: Chapter 1: Safety

    Safety Intended use The Cardiac Science 5300/5350 Vital Signs Monitor is intended to monitor a single patient’s vital signs in the hospital, acute care settings, outpatient surgery, healthcare practitioner facilities or in an environment where patient care is provided by qualified healthcare personnel who will determine when use of this device is indicated, based upon their professional assessment of the patient’s medical condition.

  • Page 12: Vital Signs Monitor Orderable Part Number Legend

    T—Temperature 0—None Printer P—Printer Future 01—Reserved for future use For Example: V530BNTP01—Cardiac Science 5300 Vital Signs Monitor Standard with NIBP, ◆ Nellcor Sp0 , Temperature, Printer V535B0TP01—Cardiac Science 5350 Vital Signs Monitor, Alarms, Intervals, NIBP, ◆ Temperature, Printer V550BMTP01—Cardiac Science 5500 Vital Signs Monitor, ECG, Masimo, ◆...
  • Page 13 Number NIBP Nellcor® Masimo® Temp Recorder Alarm Interval V535BNTP01 V535BMTP01 V535BN0P01 V535BM0P01 V535B0TP01 V535B00P01 V535BNT001 V535BMT001 V535BN0001 V535BM0001 V535B0T001 V535B00001 V530BNTP01 V530BMTP01 V530BN0P01 V530BM0P01 V530B0TP01 V530B00P01 V530BNT001 V530BMT001 V530BN0001 V530BM0001 V530B0T001 V530B00001 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 14: Warnings And Cautions

    There is smoke or a strange odor leaking out of the device. • The device has been dropped or impacted by an object. • Liquid or foreign matter gets inside the device. • If you think the device may be broken. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 15 Do not open, disassemble or alter the device. Caution The 5300/5350 series conforms to the requirements of the EMC standard (IEC 60601-1- 2:2001), so it can be used at the same time as other electrical simulators. However, it may be affected by electrical scalpels and microwave treatment devices and there may be an impact on measurement precision for patients using cardiac pacemakers and the like.

  • Page 16: Installation

    (such as an MRI room, CT room, X-ray room, etc.) Caution Do not place anything on this device. Caution Before moving this device, remove all accessories from the patient, turn the power OFF, and unplug the AC adapter cable. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 17: Nibp

    Do not measure continuously for a long time. This can cause extremity function obstruction. Caution If the cuff is touched or the patient moves, the device may interpret that the inflation pressure is insufficient and inflate to high pressure. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 18: Spo 2

    Possession or purchase of this device does not convey any express or implied license to use the device with unauthorized sensors or cables which would, alone or in combination with this device, fall within the scope of one more of the patents relating to this device. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 19: Temperature

    Temperature Caution For best product performance and measurement accuracy, use only accessories supplied or recommended by Cardiac Science. Use accessories according to the manufacturer's directions for use. Caution Never reuse a probe cover. Doing so would create a danger of infection.

  • Page 20: Internal Battery

    AC socket to prevent electric shock. Caution Do not soak the main unit or accessories in any medical liquid. Also, keep liquids out of the main unit and accessories. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 1-11...

  • Page 21: Other Labels

    Check the patient and the machine. The measurement reading will be displayed flashing. The format of the medium-priority alarm is as follows. This alarm is sounded twice at 24 second intervals. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 1-12...

  • Page 22: Symbols And Labels

    Symbols and labels Symbols and labels Cardiac Science Corporation products display one or more of these symbols and warning labels for your protection. Symbol Description Systolic Pressure Mean Arterial Pressure Diastolic Pressure Pulse Rate Arterial Oxygen Saturation by Pulse Oximeter...
  • Page 23 Body temperature measurement terminal Cuff connection terminal External input/output terminal Indoor use only Manufacturer Manufacture date Orderable part number Serial number Sold by prescription only Direct current Keep upright Fragile Use by date 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 1-14...
  • Page 24 Temperature limitations, do not exceed the given temperature limits. Relative humidity limits Pressure limitations UL Classified WITH RESPECT TO ELECTRICAL SHOCK, FIRE, AND MECHANICAL HAZARDS ONLY (For Canada and the U. S.) Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 1-15...
  • Page 25 Safety 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 1-16...
  • Page 26 Outline Contents Configured products ◆ Names and functions of parts ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 27: Chapter 2: Outline

    Outline Configured products Before using the 5300/5350 series monitor be sure to check that all of the accessories are included and that the main unit and accessories are not damaged. If, for some reason, the contents are not complete, please contact Cardiac Science.
  • Page 28 Configured products REGISTRATION CARD END USER TERMS and CONDITIONS ACCESSORY RE-ORDER FORM SERVICE MANUAL on CD Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 29 Reusable Cuff, Adult NIBP MEASUREMENT Reusable Cuff, Large Adult Rectus Cuff Hose, Adult 10 feet DURASENSOR® Patient Weight: 40kg or over EXTENSION CABLE MEASUREMENT Models with Nellcor® SpO NELLCOR DISPOSABLE SAMPLE PACK 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 30 TEMPERATURE PROBE (Oral/ Axillary) TEMPERATURE MEASUREMENT Models with Body Temperature Measurement TEMPERATURE PROBE COVERS Note: Do not use any probe or probe cover other than those specified. OTHER Models with Recorder ROLL PAPER(2pcs) Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 31: Names And Functions Of Parts

    To read patient ID, connect BAR CODE READER here. (BAR CODE READER is an option.) USB Port To use a BAR CODE READER, refer to the manual Bar Code Reader Instruction Manual. *1: Only models with body temperature measurement. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 32 Pulse Oximeter (SpO The SpO cable is connected here. Record switch Starts and stops recorder printing. *1: Only models with body temperature measurement. *2: Only models with recorder. *3: Only models with SpO Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 33: Explanation Of Display

    Chapter 11, Internal Battery.) Displays the operability status of the internal battery. Battery Icon (For details, see Chapter 11, Internal Battery.) Note: Some models of the lineup lack some LEDs, icons, and indicators. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 34 Preparation Contents Preparations before use ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 35: Preparations Before Use

    Fit the internal battery into the rear of the main unit. Use the three screws to fasten the battery cover in its original place. Screw Screw Screw Internal battery Battery cover 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 36: Connecting The Power Supply

    Connect the power supply connector of the AC adapter to the main unit. Plug the AC adapter cable plug side into a medical 3-pole wall socket with ground connector. Power supply connector of the AC adapter AC adapter AC adapter cable Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 37: Charging The Internal Battery

    Completely charge the battery before starting to use this device. Caution In order to maintain the battery charge, Cardiac Science recommends leaving the monitor plugged into AC power when it is not in use. If the monitor is not plugged in, the battery may lose its charge over time, even when powered off.

  • Page 38: Checking And Revising The Date And Time

    Enter the setting value with the Menu/Enter switch and move to the next setting item. Exiting the setting screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 39 Preparation 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 40 How to apply the cuff ◆ Manual measurement ◆ Automatic measurement (Cardiac Science 5350 only) 4-11 ◆ Continuous measurement (Cardiac Science 5350 only) 4-13 ◆ Other functions 4-16 ◆ After measurement 4-25 ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 41: Chapter 4: Non-Invasive Blood Pressure Measurement

    Size Measurement mode Air hose Infant (Pediatric) 8-14 cm Child / Small Adult 14-24 cm Rectus Cuff Hose Adult 27-46 cm Adult Adult 10 feet Large Adult 46-63 cm Thigh 38-50 cm 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 42: Check Before Start Of Blood Pressure Measurement

    After the check ends, the NIBP UNIT ICON and NIBP PATIENT ICON are lit up. Check that these icons are lit up before starting blood pressure measurement. Pressure stability check underway After completion of pressure stability check Example: When Adult/Pediatric and mmHg are set Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 43: Selecting The Measurement Mode

    When you do, the selection screen display moves to the next setting item. Exiting the selection screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 44: Cuff Connection

    Firmly insert the for-single-use cuff hose connector into the cuff hose connector. For-Single-Use Cuff Cuff Hose (Pink) (Optional) Note: Make sure that the connectors are tightly connected, as air leaks will prevent accurate measurement. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 45: How To Apply The Cuff

    Wrap the cuff so that you can insert only two fingers between the cuff and arm • above and below the cuff.(Adult) Wrap the cuff so that you can insert only one finger between the cuff and arm • above and below the cuff.(Child/Infant) 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 46 Keep the level of the cuff at the same level as the heart during the measurement. Maintain the height of the cuff-wrapped upper arm artery to that of the heart’s right ventricle during measurements. Heart Upper arm artery Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 47: Attaching Neonatal Cuff

    The blood pressure reading will be incorrect if the height of the cuff (side position, etc.) and the heart differ. A 4 in. difference may cause the blood pressure reading to differ by a maximum of 7 to 8 mmHg. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 48: Manual Measurement

    If pressurization is insufficient, the pressure will automatically increase until the ◆ correct pressure is reached (this may occur even during a measurement). To interrupt a measurement, press the Cuff Start/Stop switch. ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 49: Display Of The Measurement Results

    Be careful not to use too thick of a piece of cloth, as this prevents sufficient constriction of the arm, which will cause the blood pressure measurement to be high. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-10...

  • Page 50: Automatic Measurement (Cardiac Science 5350 Only)

    (Display example: 30-minute interval) If you do not press a switch for 10 seconds or press Cuff Start/Stop, Alarm Silence or Cuff Interval, Setting Mode ends and the display returns to the basic screen. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-11...
  • Page 51 Note: For patient safety, beware of the following when the time interval is one minute. • The measurement interval will automatically become 2.5 minutes after 12 minutes have elapsed. • If the monitor is turned off, the cuff measurement interval becomes 2.5 minutes. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-12...

  • Page 52: Continuous Measurement (Cardiac Science 5350 Only)

    Cuff Interval, Setting Mode ends and the display returns to the basic screen. (Settings are not finalized until you press the Cuff Start/Stop switch.) Pressing the Cuff Start/Stop switch starts measurement. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-13...

  • Page 53: Quick Sys

    When Quick SYS is working (when the systolic pressure can be estimated), the estimated systolic pressure value is displayed at SYS and "---" is displayed at DIA. Quick SYS display (Systolic pressure estimated value) "---" is displayed at this section. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-14...
  • Page 54 When measurement ends The measurement results are displayed. The value displayed for Quick SYS is an estimated value, so it does not necessarily match the measured systolic pressure. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-15...

  • Page 55: Other Functions

    Smart Inflation is set to OFF when the Cuff Start/Stop switch is pressed and the blood pressure is measured. (5350 only) For the 5300, this is the inflation value when Smart Inflation is set to OFF. Adult mode—You can select from 140 mmHg, 180 mmHg, and 220 mmHg.
  • Page 56 When you have selected the desired value, press the Menu/Enter switch to enter that value. Exiting the setting screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-17...
  • Page 57 When you do, the setting screen display moves to the next setting item. Exiting the setting screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-18...

  • Page 58: Elapsed Time

    When the Cuff Interval is set to 2 minutes or more. (5350 only) ◆ Smart Inflation is set to ON. ◆ (The 5300 has no interval condition.) About Utility Mode In order to switch Smart Inflation ON/OFF, it is necessary to put this unit into Utility Mode.
  • Page 59 When the patient's pulse is weak, when measuring through thick clothing, and any other case in which an adequate oscillometric signal can not be detected. • When noise, for example from body movement, is mixed in with the oscillometric signal. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-20...

  • Page 60: High Speed Measurement (Default Setting Is Off)

    BP SPD is displayed. The current setting value is displayed. Display example: ON High speed measurement selection Use the Forward or Back switch to high speed measurement ON/OFF. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-21...

  • Page 61: Bp Silent Mode

    Press the Menu/Enter switch until the BP Silent Mode Selection screen appears. When the BP Silent Mode Selection screen appears, the display becomes as follows: BP SLT is displayed. The current setting value is displayed. Display example: ON 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-22...
  • Page 62 When you do, the selection screen display moves to the next setting item. Exiting the selection screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-23...

  • Page 63: Blood Pressure Measurement End Sound

    When you do, the selection screen display moves to the next setting item. Exiting the selection screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-24...

  • Page 64: After Measurement

    Cuff Measurement Interval to OFF. For details about how to check the data, Chapter 7, List Screen Chapter 9, Recorder. The 5300 has no interval setting. Cuff measurement interval OFF (Cardiac Science 5350 only) When you press the Cuff Interval switch, the cuff measurement interval setting value flashes.
  • Page 65 (This is not applicable when NIBP and SpO measurements are simultaneously taken.) After the measurement starts with the Cuff Interval set to OFF. (5350 only) ◆ (This is not applicable when NIBP and SpO measurements are simultaneously taken.) 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-26...

  • Page 66: Clear Display (Cardiac Science 5300 Only)

    Clear measurement value display Each time you press the Clear switch, the measurement value display is cleared. Press this when the patient is changed. Usage method Press the Clear switch. Clear switch Display Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 4-27...
  • Page 67 Non-Invasive Blood Pressure Measurement 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 4-28...
  • Page 68 Pulse Oximeter (SpO (Only models with SpO Contents Measurement preparation ◆ Attaching SpO sensor ◆ Measurement ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 69: Chapter 5: Pulse Oximeter (Spo 2 )

    To disconnect, press the top and bottom arrow sections and remove. Insertion direction caution (Connector only fits one way.) Insert the OXISENSOR® onto the extension cable, lower the cover, and lock it. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 70 To disconnect, press the top and bottom arrow sections and remove. Insertion direction caution (Connector only fits one way.) Insert the SpO sensor onto the extension cable, lower the cover, and lock it. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 71: Spo 2 Sensor Selection

    40kg. ADULT NASAL OXISENSOR® MAX-R Disposable nasal sensor for adults weighing over 50kg. DURASENSOR® DS-100A Reusable sensor should be applied to adults weighing over 40kg. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 72 Purchase of this instrument confers no express or implied license under any Nellcor patent to use this instrument with any oximetry sensor that is not manufactured or licensed by Nellcor. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 73 The LNCS DC-I is a short-term reusable finger sensor. ◆ The other disposable sensors can be reused on the same patient only while the tape ◆ remains adhesive. Note: Do not use any SpO sensor other than those specified. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 74: Attaching Spo 2 Sensor

    Check that the clip is not pressing too hard and creating excess pressure on the finger. ◆ Be particularly careful of the finger tip. If the clip is pressing too hard, the sensor can be mounted on the little finger. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 75: Disposable Spo 2 Sensor

    When attaching to a finger, have the light emitting surface on the nail side. Light emitting surface Always attach on the corresponding surface. Light receiving surface 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 76: Measurement

    • When there is strong light, such as direct illumination or direct sunlight. (Block off the light.) • Measurements on patients using a heart-lung machine (since there is no pulsebeat). Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 77 4-26) (5300 only) In the following cases, the display is automatically cleared. After measurement starts. (5300 only) ◆ After measurement starts with the Cuff Interval set to OFF. (5350 only) ◆ 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 5-10...
  • Page 78 Temperature Measurement (Only models with body temperature measurement) Contents Measurement preparation ◆ Measurement ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 79: Measurement Preparation

    To connect the connector, push in until the connector clicks into place. To disconnect the connector, while restraining the upper section, lock, pull out Note: Do not use any probe or probe cover other than those specified. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 80: Measurement

    If the cover is not securely mounted, there is a danger of it coming loose or coming off in use. Also, be careful not to press the probe cover removal button by mistake during use. Probe cover removal button Body temperature probe Probe cover Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 81: Mounting The Body Temperature Probe

    After about 10 seconds, the body temperature can be measured. Hold the body temperature probe position constant and in such a way that its tip is ◆ touching the patient's skin during body temperature measurement. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 82: Screen Display Example

    Failed to estimated body temperature after 60 seconds when the measurement was started. Note: If an unusually high or low temperature reading is obtained, confirm the reading using another temperature measuring device before beginning any treatment. Screen display example Body temperature value Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 83: Exiting Measurement

    Chapter 7, List Screen Chapter 9, Recorder. Clear display When using on a different patient, press the Clear switch. (Page 3-18)(5300 only) ◆ In the following cases, the display is automatically cleared. When an estimated measurement ends. (5300 only) ◆...
  • Page 84 List Screen Contents Explanation list screen ◆ List data count ◆ List save timing ◆ Deleting list data ◆ Exiting list display ◆ This can display past measurements (List Data) stored in memory. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 85: Explanation List Screen

    List display isn't displayed in the following cases: When measuring the blood pressure. ◆ When measuring the SpO ◆ When measuring the body temperature. ◆ When the alarm is activated. ◆ When there is no list data. ◆ 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 86: List Data Count

    When measurement with the cuff is completed (including error). ◆ When an alarm occurs with each measurement reading (5350 only). ◆ When SpO measurement starts. ◆ When estimated body temperature ends. ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 87: Deleting List Data

    Exiting the setting screen If you do not press a switch for 10 seconds or press Cuff Start/Stop or Alarm Silence, Setting Mode ends and the display returns to the basic screen. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 88: Exiting List Display

    10 seconds passes without any key operation. ◆ If a switch other than the Forward or Back switch is pressed. ◆ If the alarm is activated. ◆ If blood pressure measurement is started. ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 89 List Screen 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 90 Alarms (Cardiac Science 5350 only) Contents Alarm settings (Cardiac Science 5350 only) ◆ Alarm operations (Cardiac Science 5350 only) ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 91: Alarm Settings (Cardiac Science 5350 Only)

    Press the Menu/Enter switch until the Alarm Setting screen you want to change appears. Here are the following types of Alarm Setting screens: SYS upper limit SYS lower limit DIA upper limit DIA lower limit PR upper limit PR lower limit upper limit lower limit 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 92: Changing The Alarm Setting Value

    Exiting the setting screen If you do not press a switch for 10 seconds or press Cuff Start/Stop or Alarm Silence, Setting Mode ends and the display returns to the basic screen. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 93: Alarm Operations (Cardiac Science 5350 Only)

    The data is automatically stored in the list. ◆ The alarm sounds. The alarm lamp flashes. The corresponding measurement value is displayed flashing. The edge of the Alarm Silence switch flashes. The data is automatically stored in the list. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 94: Silencing An Alarm

    For either type of alarm, if an alarm has ended, then occurs again, the alarm sounds. Extinguishing an alarm When the patient's measurement value returns into the monitoring range, the above display returns to normal. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 95: Alarm Setting Range

    Note: No alarm is issued until the measured value exceeds the upper alarm setting or falls below the lower alarm setting. Note: For details on the alarm sound see Other labels on page 1-12. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 96 Recorder (Only models with recorder) Contents Preparations before use ◆ Manual recording ◆ Automatic recording ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 97: Preparations Before Use

    For the above reasons, make a copy when storing as a document of permanent record. Note: Please use only roll paper from Cardiac Science. If you use other paper, the printing may be thin or it may cause a paper jam or other breakdown.

  • Page 98: Manual Recording

    For details about how to set the list type, see List record pattern selection on page 9-7. Simple List Recording (LST 1)(Default) ◆ Detailed List Recording (LST 2) ◆ Measurement Value Recording (OSCL) ◆ All list recording ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 99: Simple List Recording (Lst 1)

    The TEMP data is displayed only for models with body temperature measurement. ◆ The latest 10 data items are printed on one page. ◆ Note: Inputting an ID requires the optional bar code reader. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 100: Detailed List Recording (Lst 2)

    When any of the NIBP unit (mmHg/kPa), TEMP unit (°C/°F) or measurement mode ◆ (Adult/Neonate) changes, it starts to print from next page. Note: Inputting an ID requires the optional bar code reader. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 101: Measurement Value Recording (Oscl)

    If you hold down the record switch for 3 seconds or longer, the entire list is printed. Up to 400 items can be printed in a list. As an exception, when you select OSCL as the list type, LST1 list will be printed automatically in the all list recording. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 102: List Record Pattern Selection

    When you do, the selection screen display moves to the next setting item. Exiting the selection screen To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 103: Automatic Recording

    SpO measurement. ◆ The TEMP data is displayed only for models with body temperature measurement. ◆ Note: Inputting an ID requires the optional bar code reader. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 104: Measurement Value Recording (Oscl)

    The TEMP data is recorded only for models with body temperature measurement. ◆ Note: The SpO measurement value printed is the data for when cuff measurement starts. Note: Inputting an ID requires the optional bar code reader. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 105: Measurement Record Selection

    PRT AUT is displayed One of these displays:. Do not record Simple list recording Measurement value recording Selecting the recording for measurement Use the Forward or Back switch to select the recording for measurement. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 9-10...

  • Page 106: Deleting List Data

    Flashing slowly error If the paper runs out during printing, reload paper. The printing does not resume automatically. Press the Record switch. Note that the printing starts over from the beginning. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 9-11...
  • Page 107 Recorder 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 9-12...
  • Page 108 Setup Contents How to setup 10-2 ◆ Setting Mode 10-4 ◆ Utility Mode 10-11 ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-1...

  • Page 109: How To Setup

    Blood pressure measurement end sound ON/OFF selection Measurement record selection (only for models with recorder) List record pattern selection (only for models with recorder) External output selection Battery operation selection Hour setting Minute setting 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-2...
  • Page 110 Day setting Date format selection (only for models with recorder) Map display ON/OFF selection LAN group number setting** LAN bed number setting** Default setting *5350 only **Only when External output is selected. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-3...

  • Page 111: Setting Mode

    In this case, the setting value at that time is finalized. (5350 only) 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-4...

  • Page 112: Setting Method For Each Item

    DIA upper limit alarm setting (5350 only) This sets the DIA upper limit alarm value. For details, see Alarm settings (Cardiac Science 5350 only) on page 8-2. The current setting value HI: upper limit Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-5...
  • Page 113 (5350 only) This sets the SpO upper limit alarm value. For details, see Alarm settings (Cardiac Science 5350 only) on page 8-2. The current setting value HI: upper limit 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-6...
  • Page 114 Exiting the setting screen • If you do not press a switch for 10 seconds or press Cuff Start/Stop or Alarm Silence, Setting Mode ends and the display returns to the basic screen. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-7...
  • Page 115 Exiting the setting screen • If you do not press a switch for 10 seconds or press Cuff Start/Stop or Alarm Silence, Setting Mode ends and the display returns to the basic screen. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-8...
  • Page 116 Exiting the selection screen • If you do not press a switch for 10 seconds or press Cuff Start/Stop or Alarm Silence, Setting Mode ends and the display returns to the basic screen. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-9...
  • Page 117 The list data is erased. For details, see Deleting list data on page 7-4. DEL LST is displayed. Hold down the Alarm Silence switch for at least 3 seconds. DONE is displayed. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-10...

  • Page 118: Utility Mode

    Date format selection (only for models with recorder) Map display ON/OFF selection LAN group number setting** LAN bed number setting** Default setting ** May not display depending on the External output switching. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-11...

  • Page 119: Setting Method For Each Item

    Inflation are set to OFF, the Cuff Start/Stop switch is pressed and the blood pressure is measured. (5350 only) For the 5300, this is the inflation value when Smart Inflation is set to OFF. For details, see Initial inflation value on page 4-16.
  • Page 120 Inflation are set to OFF, the Cuff Start/Stop switch is pressed and the blood pressure is measured. (5350 only) For the 5300, this is the inflation value when Smart Inflation is set to OFF. For details, see Initial inflation pressure value setting on page 4-16.
  • Page 121 When this function is switched ON, the pump sound is suppressed. For details, see BP silent mode on page 4-22 BP SLT is displayed. The current selection is displayed. Display example: ON 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-14...
  • Page 122 When this function is switched ON, a sound is played when blood pressure measurement ends. For details, see Blood pressure measurement end sound on page 4-24. BP SND is displayed. The current selection is displayed. Display example: ON Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-15...
  • Page 123 Select any one of the above. For details, see Automatic recording on page 9-8. PRT AUT is displayed One of these displays:. OFF—Do not record LST—Simple list recording OSCL—Measurement value recording 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-16...
  • Page 124 One of these displays:. LST—Simple list recording LST2—Detailed list recording OSCL—Measurement value recording External output selection This screen makes settings related to external output selection. Contact Cardiac Science Technical Support when making these selections. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-17...
  • Page 125 When you do, the selection screen display moves to the next setting item. Exiting the selection screen • To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-18...
  • Page 126 Checking and revising the date and time on page 3-5. Year setting Month setting This sets the month for the clock. For details, see Checking and revising the date and time on page 3-5. Month setting Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 10-19...
  • Page 127 When you do, the selection screen display moves to the next setting item. Exiting the selection screen • To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-20...
  • Page 128 ON again. LAN group number setting This screen makes settings related to LAN group numbers. Contact Cardiac Science Technical Support when making these settings. (May not display depending on the External output switching.) LAN bed number setting This screen makes settings related to LAN bed numbers.
  • Page 129 Hold down the Alarm Silence switch for at least 3 seconds. DONE is displayed. Exiting the setting screen • To end Utility Mode and return to the basic screen, switch the power OFF, then ON again. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 10-22...
  • Page 130 Charging types and battery indicator display 11-2 ◆ Battery icon display 11-3 ◆ Battery low 11-3 ◆ Battery not mounted 11-3 ◆ Operating time 11-4 ◆ Battery and ambient temperature 11-4 ◆ Warranty 11-4 ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 11-1...

  • Page 131: About The Internal Battery

    This battery is a lead acid battery. Caution In order to maintain the battery charge, Cardiac Science recommends leaving the monitor plugged into AC power when it is not in use. If the monitor is not plugged in, the battery may lose its charge over time, even when powered off.

  • Page 132: Battery Icon Display

    If the battery is not mounted, the E90 error is displayed when the power is switched ON. The alarm can be silenced with the Alarm Silence switch. ◆ The unit can be used with the AC adapter but clock data and settings data are not ◆ stored. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A 11-3...

  • Page 133: Operating Time

    Charging the battery outside this temperature range can cause battery fluid leakage, heat generation, etc. This can also reduce performance and service life. Warranty The internal battery is a consumable part, so it is not covered by the limited warranty. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor 11-4...
  • Page 134 Error code table ◆ Principles A-14 ◆ Default setting A-19 ◆ Maintenance A-21 ◆ Checking before use A-24 ◆ Maintenance checks A-26 ◆ Troubleshooting A-27 ◆ Disposal A-31 ◆ Specifications A-32 ◆ Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 135: Error Code Table

    Cardiac Science Technical Support. Either no internal battery is mounted or Either no internal battery is it cannot be detected. High Possible mounted or it cannot be Check the internal battery cable detected. connection. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 136 Support. A device error was detected. Switch the power OFF, then ON again. If the error High Possible System error recurs repeatedly, stop using this device and contact Cardiac Science Technical Support. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 137: Non-Invasive Blood Pressure (Nibp) Measurement Section Error Code List

    Check the BPM IEC standards. patient and conditions of measurement, and measure again with the cuff. Cease use immediately if the E09 error recurs and contact Cardiac Science Technical Support. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 138 When the error still occurs even after checking above, there is a possibility that the cuff is torn and air is leaking. Replace it with a new one. * For 5300, the alarm does not sound. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 139 Check to make sure cuff is not wrapped around thick clothing, 4th time the patient stays still and that High the cuff is free from outside vibrations, measure again. * For 5300, the alarm does not sound. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 140 Motion artifact or vibration from outside possibly affected cuffs. Check whether a patient stays 3rd time still and cuff is free from outside High vibration, measure again. * For 5300, the alarm does not sound. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...
  • Page 141 If switching power OFF/ON has into the unit no effect it is possible that a fault has occurred. Contact Cardiac Science Technical Support. * For 5300, the alarm does not sound. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...
  • Page 142 ◆ setting. In the case of E11 to E21, it can be checked at "List screen" or "Recorder". The number of remeasurements is counted irrespective of which error code is ◆ detected. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A...

  • Page 143: Spo 2 Error Code Table

    Also, do not move the sensor measurement range mounting location. Check the condition of the patient. None Pulse signal weak Also, check that the sensor is correctly mounted. *For 5300, the alarm does not sound. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-10...
  • Page 144 An impossible Cardiac Science Technical Support. measurement value was obtained. *For 5300, the alarm does not sound. In case of some errors, for example E33, E34, E36, the SpO measurement value and ◆ the error code are displayed alternately. The SpO measurement value is displayed for about 9 seconds and the error code for about 1 second.

  • Page 145: Body Temperature Error Code Table

    Replace the probe. If replacing the probe does not solve the problem, Medium Possible Probe breakdown stop using body temperature measurement and contact Cardiac Science Technical Support. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-12...
  • Page 146 Technical Support. measurement value was obtained. *For 5300, the alarm does not sound. In case of E40, E41, the error code may not be displayed depending on the setting. ◆ If E40-42 occurs before the first measurement value is obtained, either there is no ◆...

  • Page 147: Principles

    Therefore, it is not easily affected by external noise, an electric scalpel or other electro surgical instruments. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-14...

  • Page 148: Basic Principles Of Spo 2 Measurement

    Usually, an artery with a high ratio of oxidized hemoglobin is red while a low ratio will cause the venous blood to look blackish. This is easily understood when the light absorbency coefficient of wavelengths for each hemoglobin type are viewed. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-15...
  • Page 149 Subtraction of the standard reading from the systolic reading provides a reading that is the level of oxygen saturation for arterial blood. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-16...

  • Page 150: Principle Of Operation (For Masimo® Model

    R=S1/S2 Again, R is the ratio of two arterial pulse-added absorbance signals and its value is used to find the saturation SpO in an empirically derived equation into the oximeter's software. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-17...
  • Page 151 The MS board SpO therefore corresponds to a running average of arterial hemoglobin saturation that is updated every two seconds. DST® is a registered trademark of Masimo Corporation. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-18...

  • Page 152: Default Setting

    Alarm* Upper limit 180/min Lower limit 40/min Upper limit 200/min (Neo) Lower limit 50/min Upper limit 100%SpO  Lower limit 90%SpO Upper limit 100%SpO  (Neo) Lower limit 85%SpO *5350 only Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-19...
  • Page 153 Recording for blood pressure measurement Recorder Simple list List record pattern recording External output switching Battery operation SAVE Date format YYYY/MM/DD System MAP display LAN group number LAN bed number *5350 only 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-20...

  • Page 154: Maintenance

    Maintenance Maintenance Maintenance inspection and safety management Medical equipment including the 5300/5350 series must be maintained to ensure functionality and to secure the safety of patients and operators. Daily checks and maintenance should be performed by the operator. In addition, qualified personnel are necessary to maintain the performance and the safety, and to conduct periodic inspections.

  • Page 155: Device Maintenance

    For more information, refer to the monitor service manual. Qualified service personnel in the user's institution should perform periodic inspections of the monitor. If service is necessary, contact qualified service personnel or Cardiac Science Technical Support. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 156: Accessory Care

    Cidex®, Betadine®, 10% solution of bleach (9 parts water, one part bleach), 3% Hydrogen peroxide. Cidex® is a registered trademark of Johnson & Johnson. Betadine® is a registered trademark of Purdue Products, L.P. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-23...

  • Page 157: Checking Before Use

    • pulse oximeter (SpO value is displayed. measurement section** • Press the Record switch and check that the instrument Printer * is recording. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-24...
  • Page 158 106°F) and check that the temperature difference is within ±0.2°C(0.4°F). * Only for models with the optional recorder. **Only for models with the optional SpO ***Only for models with the optional temperature. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-25...

  • Page 159: Maintenance Checks

    Do items light up that should light up when a switch is pressed? Alarm volume check Is the warning sound clearly audible? • Time • Check to see that the time is correct. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-26...

  • Page 160: Troubleshooting

    The following are possible causes. Re-measure while physically examining patient. Body moved (shivering due to cold, etc.). • Abnormal measurement readings Arrhythmia occurred. • • Noise in cuff. (Nearby person touched patient or heart massage was being performed.) Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-27...
  • Page 161 Cuff size and/or cuff wrapping were incorrect. • Cuff was wrapped at a position on the upper arm not parallel to the heart. • Patient blood pressure was unstable due to alternating pulse and respiration fluctuations, etc. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-28...

  • Page 162: Arterial Oxygen Saturation By Pulse Oximeter Measurement (Spo 2

    If sensor becomes detached or light intensity changes due • to somebody blocking out light source as he/she walks by, etc., erroneous measurement readings may be displayed. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-29...

  • Page 163: Problems With E-Temp

    Improper probe placement techniques, this fast measurement requires the user to make sure the probe is placed directly against the sublingual artery in the back, center of the tongue. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-30...

  • Page 164: Disposal

    Main Unit and Accessories Chassis Aluminum and Iron Battery Lead-acid Enclosure Option Module Trigger Button (Bar Code Reader) Internal parts General Electric Parts Option Module Enclosure (External Output Unit) Internal parts General Electric Parts Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-31...
  • Page 165 Blood pressure unit display Green Flat LED Measurement mode display Green Flat LED Recorder display Red Flat LED Battery Charging Indicator Green/Orange/Red Flat LED Volume (Sound pressure Alarm Signals 40 to 53 dB range) 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-32...

  • Page 166: Specifications

    Type BF with defibrillator protection Type BF with Degree of Protection NIBP defibrillator protection Type BF Temperature Mode of Operation: Continuous Class II a (5300 only) MDD Classification: Class II b (5350 only) Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-33...

  • Page 167: General

    IEC 60601-1-1. If in doubt, consult your technical services department or Cardiac Science Technical Support. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor...

  • Page 168: Environmental Conditions

    10 to 95% (not condensed) Atmospheric pressure 500 to 1060hPa IEC60601-1-2:2001 Medical electrical equipment Part1: General requirements for EMC: Reference standard safety. 2.Collateral Standard Electromagnetic compatibility- Requirements and tests. EN55011:1998 Group1 Class B Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-35...

  • Page 169: Non-Invasive Blood Pressure (Nibp

    Default 160 mmHg limit 30 to 230 mmHg DIA lower Default 30 mmHg limit 30 to 260/min Pulse rate upper Default 180/min limit 25 to 255/min Pulse rate lower Default 40/min 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-36...
  • Page 170 25 to 255/min Pulse rate lower Default 50/min EN1060-1:1995+A1:2002 Non-invasive sphygmomanometers General requirements EN1060-3:1997+A1:2005 Reference Standard: Non-Invasive sphygmomanometers - Part3: Supplementary requirements for electro-mechanical blood pressure measuring systems. ANSI/AAMI SP-10:2002 Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-37...
  • Page 171 Pulse oximeter sensors contain LEDs that emit red light at a wavelength of approximately 660nm and infrared light at a Range of Peak Wavelength wavelength of approximately 920nm. The total optical power of the sensor LEDs is less than 15mw. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-38...
  • Page 172 Pulse rate upper Default 180/min (adult) 200/min (Neo) limit 25 to 255/min Pulse rate lower Default 40/min (adult) 50/min (Neo) Maximum delay time 10 sec Alarm delay time Average delay time 10 sec Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-39...

  • Page 173: Pulse Oximeter (Models With Nellcor® Spo 2

    0 to 69% Unspecified Pulse oximeter sensors contain LEDs that emit red light at a Range of Peak Wavelength wavelength of approximately 660nm and infrared light at a wavelength of approximately 905nm. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-40...
  • Page 174 Pulse rate upper Default 180/min (adult) 200/min (Neo) limit 25 to 255/min Pulse rate lower Default 40/min (adult) 50/min (Neo) Maximum delay time 10 sec Alarm delay time Average delay time 10 sec Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-41...

  • Page 175: E-Temp

    Selectable from °F to °C This thermometer conforms to all of the requirements established in ASTM standard E 1112. Full responsibility for conformance of this product to the specification is assumed by Cardiac Science. 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-42...

  • Page 176: Fcc Statement

    Clase B prescrites dans la norme sur le materiel brouilleur: "Appareils Numeriques", ICES-003 edictee par le minister des communications. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Cardiac Science 5300/5350 Vital Signs Monitor 70-00582-01 A A-43...

  • Page 177: Manufacturer's Declaration

    Appendix Manufacturer’s declaration Use the 5300/5350 in an electromagnetic environment as described below. The user should check that the 5300/5350 is used in such an environment. Electromagnetic Emissions: (IEC60601-1-2) Table 1: Guidance and manufacturer's declaration - electromagnetic emissions Emissions Test...
  • Page 178 Mains power quality should be that of a typical commercial or for 5 cycles for 5 cycles interruptions and voltage hospital environment. If the user of the 5300/5350 requires variations on power continued operation during power mains interruptions, it is supply recommended that the 5300/5350 be powered from an <70% U...
  • Page 179 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the 5300/5350 is used exceeds the applicable RF compliance level above, the 5300/5350 should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the 5300/5350.
  • Page 180 5300/5350 The 5300/5350 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the 5300/5350 can help prevent electromagnetic interference by maintaining a minimum distance between...
  • Page 181 Appendix 70-00582-01 A Cardiac Science 5300/5350 Vital Signs Monitor A-48...
  • Page 182 Cardiac Science Corporation • 3303 Monte Villa Parkway, Bothell, WA 98021 USA • 425.402.2000 • US toll-free 800.426.0337 • Fax: 425.402.2001 • info@cardiacscience.com Orders and Customer Care (US and International) • 425.402.2000 • US toll-free 800.426.0337 • Fax: 425.402.2001 • care@cardiacscience.com Technical Support •...

This manual is also suitable for:

V535bntp01V535bm0p01V535bn0p015350V535b0tp01V535b00p01 ... Show all

Table of Contents
