Lists And System Notes - Cardiac Science Eclipse Premier Operating Instructions Manual

Chapter 3
Keyboard and Displays

Lists and System Notes

Figure 3-4
A Sample List - The
Medication List
3-8
Eclipse Operating Instructions
LISTS
Lists give you all the choices for a particular field. For example, scroll to Medication 1.
A list appears (see Figure 3-4). The field may be filled with any choice from this list.
After you make a selection, the next field becomes active.
ID:0123456789
( * I t e m s m a y a f f e c t c o m p u t e r a n a l y s i s )
* V 3 P l a c e m e n t : S T A N D A R D
P a t i e n t I D
L a s t N a m e
F i r s t N a m e
* D . O . B .
* A g e
* A g e F o r m a t
* S e x
* M e d i c a t i o n 1
* C l a s s 1
C o m m e n t s :
HOT KEYS
NOTE: If a custom header has been downloaded to the Eclipse
Premier unit, then hot keys will not appear in certain lists such as the
medication lists.
All list items have hot keys to select them.
For example, the letter "D" is underlined in the choice, "DIGITALIS." This is a hot
key; it is temporarily specialized to select this choice. Press the "D" key to select
"DIGITALIS".
Another way to select items is from within the list. You may gain access to the list by
pressing the right arrow key.
Scroll within the list using the up and down arrow keys. When your choice is
highlighted, choose it by pressing the Enter key.
To exit the list without selecting anything, press the left arrow key.
SYSTEM NOTES
System notes give you additional information as needed. For example, a system note
appears if you enter data that exceeds an allowed range.
To see a system note, scroll to the *Age field. This is a numeric field that accepts only
data between 0 and 364. Try typing a larger number such as 500. A system note box
appears.
65
x1
EDIT ID
:
:
MEDICATION
:
b l a n k
:
N O M E D I C A T I O N
:
U N K N O W N
:
D I G I T A L I S
:
D I U R E T I C
:
:
PRESS
070-1149-01 B
