Figure 4-2
A USER SETUP Menu—The
POWER-UP DEFAULTS
Menu
070-1149-01 B
ID:0123456789
S p e e d :
G a i n : 10 mm/mV
A r t i f a c t F i l t e r : 40 Hz
6. Use the up and down arrow keys to scroll through the fields in the
selected menu. As you scroll through the fields, the options available
for each field will be displayed when the field is highlighted.
7. Once a field is highlighted, change the current selection by pressing
the "hot" key associated with the option. For example, to select a speed
of 50 mm/s in the POWER-UP DEFAULTS MENU, press the "5" key.
8. Use the keyboard to enter information into fields with a blinking
cursor.
Use the left arrow key to exit the menu.
USER SETUP Menus, Fields and Options
Following are descriptions of each USER SETUP menu, with information on menu
fields and options. For each field in a menu, the available choices are listed to the right
of the field name. When applicable, the type of information and the number of
characters allowed are listed in brackets to the right of the field name.
MAIN MENU
POWER-UP DEFAULTS
25 mm/s
Configuring the USER SETUP Menus
65 PRESS
x1
SPEED
10 mm/s
25 mm/s
50 mm/s
Eclipse Operating Instructions
4-7
