Chapter 4
System Setup and User Setup
Number Of Copies
Median Complex Page
Print Mode
Save Mode
Wait for good data
Annotate R-R Intervals
4-10
Eclipse Operating Instructions
[Numeric. Range = 0-5]
Sets the number of complete report copies to print in addition to the automatic
printout.
ON
OFF
Enables Median Complex printout as part of every Auto ECG report.
AUTO
MANUAL
OFF
Determines how ECG reports are printed. If AUTO is selected, then reports
automatically print out prior to saving. If OFF is selected, no report is printed prior to
saving. If MANUAL is selected, then prior to saving the unit will display a message
asking whether to print the record.
AUTO
AUTO SAVE AND SEND
MANUAL
Determines how Auto ECG reports are saved. If AUTO is selected, reports will be
automatically saved after printing. If MANUAL save is selected, the PREVIEW
screen is displayed at the end of every Auto ECG sequence. You may save the
report at this time. If AUTO SAVE AND SEND is selected, then the report is
automatically saved; the report is also sent automatically to an ECG Management
System, such as the PYRAMIS System or the FAA System.
ON
OFF
When ON, Auto ECG reports are delayed until ten seconds of low noise waveform
have been collected (all electrodes must be connected). An immediate report can be
forced by pressing ECG a second time. In this case, if data is noisy, the report will
state "Warning: Data quality may affect computer interpretation."
When OFF, the Auto ECG report starts once at least 10 seconds of ECG waveform
has been collected, regardless of the quality of the collected waveform data. No
warning message is printed in this case.
NOTE: If any electrodes are disconnected the report will show a flat baseline for
those leads. ("Overload" conditions will also produce a flat baseline.) Leads with
disconnected electrodes will not be used in the ECG analysis.
ON
OFF
When ON, R-R intervals are printed at the bottom of the 12-lead report. For
additional information, see "R-R Intervals" on pg. 11-4.
