Potential equalisation drawings for Sigma Basic Type

18 Potential equalisation drawings for Sigma Basic Type
A.
2
1
5
B.
6
Fig. 31: Potential equalisation drawings for Sigma S3Ba; A. Pump without frame, B. Pump with frame
1 Potential equalisation of motor
2 Potential equalisation of motor flange
82
3
4
3 Potential equalisation of liquid end
P_SI_0170_SW
