Installing the Network Module
Accessing the web interface
1. Be sure that the UPS is powered on.
2. On the host computer, download the RNDIS_Serial.zip file from the
website www.powerquality.eaton.com/Support/ and extract it.
For more information, navigate to Accessing to the latest Network Module
3. Launch setProxy.bat to add 169.254.* in proxy's exceptions list, if needed.
4. Launch a supported browser, the browser window appears.
6. Enter the user name in the User Name field. The default user name is admin.
7. Enter the password in the Password field. The default password is admin.
8. Click Sign In. The Network Module local web interface appears.

3.2.5 Accessing the card through serial terminal emulation

Connecting the configuration cable

1. Connect the Micro-B to USB cable to a USB connector on the host computer.
2. Connect the cable to the Settings connector on the Network Module.
Servicing the Network Management Module – 54
firmware/driver section.
