Online - Eaton Network-M2 User Manual

Online

Diagram elements description
Sym Description
bols
Main utility or
second utility
Rectifier: convert
AC power to DC
power.
Inverter: convert
DC power to AC
power.
Output of the
UPS.
Internal battery
charger.
Battery for the
backup power.
Battery level
Possible states
Green Yellow
Powered Out of nominal
range
Powered In overload
HE mode
(ready)
Powered In overload
HE mode
(ready)
Protected In overload
Not protected
Charging
Floating
Powering the End of life
load
> 50% and > < 50% and >
low battery low battery
threshold threshold
(Settable on (Settable on
the UPS) the UPS)
Red Black or white
Not present
Unknown
In short Not powered
circuit
Unknown
In fault
In short Not powered
circuit
Unknown
In fault
In short Not powered
circuit
Unknown
In fault Resting
Not powered
Unknown
In fault Not used to
power the load
Not present
Unknown
< Below
low battery
threshold
(Settable
on the
UPS)
Contextual Help – 15
