Parameters
3.12.7 16-9* Diagnosis Read-Outs
16-90 Alarm Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word sent via the serial
*
3 3
16-91 Alarm Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the alarm word 2 sent via the
*
16-92 Warning Word
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word sent via the
*
16-93 Warning Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] View the warning word 2 sent via the
*
16-94 Ext. Status Word
Range:
0 [0 - 0xFFFFFFFFUL ] Shows the extended status word sent
*
16-95 Ext. Status Word 2
Range:
0 [0 - 0xFFFFFFFFUL ] Shows the extended status word 2 sent
*
16-97 Alarm Word 3
Range:
0 [0 - 4294967295] View the alarm word 3 sent via the serial
*
16-98 Warning Word 3
Range:
0 [0 - 4294967295] View the warning word 3 sent via the
*
84
®
VLT HVAC Basic Drive FC 101
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
serial communication port in hex code.
Function:
via the serial communication port in
hex code.
Function:
via the serial communication port in
hex code.
Function:
communication port in hex code.
Function:
serial communication port in hex code.
Danfoss A/S © 04/2018 All rights reserved.

3.13 Main Menu - Data Readouts 2 - Group

18
Parameters in this group are array parameters, where up to
10 fault logs can be viewed. [0] is the most recent logged
data, and [9] is the oldest. Fault codes, values, and time
stamp can be viewed for all logged data.
3.13.1 18-1* Fire Mode Log
18-10 FireMode Log:Event
Range: Function:
0 [0 - 255 ] View fire mode event.
*
3.13.2 18-5* Ref. & Feedb.
18-50 Sensorless Readout [unit]
Range:
0 Sensor- [-999999.999 -
lessUnit 999999.999
*
SensorlessUnit]
Function:
View the pressure or flow
resulting from the sensorless
calculations. This value is not the
value used for control. The value
is only updated if sensorless data
supports both flow and pressure.
