Parameters
5-53 Term. 29 High Ref./Feedb. Value
Range:
Function:
Size
[-4999 -
Enter the high reference value [RPM] for
related
4999 ]
the motor shaft speed and the high
*
feedback value. Select terminal 29 as a
digital input (parameter 5-13 Terminal 29
Digital Input = applicable value).
3.6.6 5-9* Bus Controlled
This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
Function:
0
[0 - 0xFFFFFFFF ] This parameter holds the state of the bus-
*
controlled digital outputs and relays.
A logical 1 indicates that the output is
high or active.
A logical 0 indicates that the output is
low or inactive.
Bit 0–3
Reserved
Bit 4
Relay 1 output terminal
Bit 6–23
Reserved
Bit 24
Terminal 42 digital output
Bit 26–31
Reserved
Table 3.5 Bit Functions
