Parameters
0-61 Access to Main Menu w/o Password
Option:
[3] Bus: Read only
[5] All: Read only

3.2 Main Menu - Load and Motor - Group 1

3 3
Parameters related to the motor nameplate load compen-
sations and application load type.
3.2.1 1-0* General Settings
1-00 Configuration Mode
Option:
[0] Open
Loop
*
[3] Process
Closed
Loop
1-01 Motor Control Principle
Option: Function:
NOTICE
[0] U/f
When running U/f, control slip and load
compensations are not included.
Used for parallel-connected motors and/or special
motor applications. Set the U/f settings in
parameter 1-55 U/f Characteristic - U and
parameter 1-56 U/f Characteristic - F.
NOTICE
[1] VVC+
*
When parameter 1-10 Motor Construction is
set to PM-enabled options, only VVC
is available.
30
VLT
Function:
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
Motor speed is determined by applying a speed
reference or by setting the wanted speed when
in hand-on mode.
Open loop is also used if the frequency
converter is part of a closed-loop control system
based on an external PI controller providing a
speed reference signal as output.
NOTICE
When set for Closed Loop, the commands
Reversing and Start Reversing do not
reverse the direction of the motor.
A reference from the built-in PI controller
determines the motor speed. The built-in PI
controller varies the motor speed as of a closed-
loop control process (for example, constant
pressure or flow). Configure the PI controller in
parameter group 20-** Drive Closed Loop.
Danfoss A/S © 04/2018 All rights reserved.
®
HVAC Basic Drive FC 101
1-01 Motor Control Principle
Option:
1-03 Torque Characteristics
Option:
[1] Variable
Torque
*
[3] Auto
Energy
Optim.
1-06 Clockwise Direction
Option:
[0] Normal The motor shaft turns in clockwise direction when
*
[1] Inverse The motor shaft turns in counterclockwise
1-08 Motor Control Bandwidth
Option:
[0] High
[1] Medium
*
[2] Low
[3] Adaptive 1 Suitable for smooth steady-state operation with
[4] Adaptive 2 This is an alternative to [3] Adaptive 1, which
+
option
Function:
Normal running mode, including slip and load
compensations.
Function:
For speed control of centrifugal pumps and fans.
Also to be used when controlling more than 1
motor from the same frequency converter (for
example, multiple condenser fans or cooling
tower fans). Provides a voltage that is optimized
for a squared torque load characteristic of the
motor.
For optimum energy efficient speed control of
centrifugal pumps and fans, it provides a
voltage that is optimized for a squared torque
load characteristic of the motor. In addition, the
AEO feature adapts the voltage exactly to the
current load situation, thereby reducing energy
consumption and audible noise from the motor.
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
This parameter defines the term clockwise
corresponding to the LCP direction arrow. Used for
easy change of direction of shaft rotation without
swapping motor wires.
frequency converter is connected U⇒U; V⇒V; and
W⇒W to motor.
direction when frequency converter is connected
U⇒U; V⇒V; and W⇒W to motor.
Function:
Suitable for highly dynamic response.
Suitable for smooth steady-state operation.
Suitable for smooth steady-state operation with
lowest dynamic response.
extra active damping.
focuses on low-inductance PM motors.
