Parameters
Digital input Description
function
[64] Counter B (down) Input for decrement counting in the SLC
counter.
[65] Reset Counter B Input for reset of counter B.
[101] Sleep A signal applied puts the frequency
converter into sleep mode.
Table 3.3 Digital Input Functions
Selected Preset
preset reference bit 2
reference:
Preset 0
reference 0
Preset 0
reference 1
Preset 0
reference 2
Preset 0
reference 3
Preset 1
reference 4
Preset 1
reference 5
Preset 1
reference 6
Preset 1
reference 7
Table 3.4 Selected Preset Reference
5-10 Terminal 18 Digital Input
Parameter for configuring the input function on input terminal
18. Refer to Table 3.3 for setting options.
Option:
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
*
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
MG18B502
Programming Guide
Preset Preset
reference bit 1 reference bit 0
0 0
0 1
1 0
1 1
0 0
0 1
1 0
1 1
Function:
Danfoss A/S © 04/2018 All rights reserved.
5-10 Terminal 18 Digital Input
Parameter for configuring the input function on input terminal
18. Refer to Table 3.3 for setting options.
Option:
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[37] Fire Mode
[52] Run permissive
[53] Hand start
[54] Auto start
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[101] Sleep
[120] Lead Pump Start
[121] Lead Pump Alternation
[130] Pump 1 Interlock
[131] Pump 2 Interlock
[132] Pump 3 Interlock
[133] Pump 4 Interlock
[134] Pump 5 Interlock
5-11 Terminal 19 Digital Input
Parameter for configuring the input function on input terminal
19.
Option:
[0] No operation
*
[1] Reset
[2] Coast inverse
[3] Coast and reset inverse
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[7] External Interlock
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[14] Jog
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[34] Ramp bit 0
[37] Fire Mode
Function:
3 3
Function:
