Parameters
Bit Bit = 0
00 Control not ready
01 VLT not ready
02 Coasting
03 No fault
04 No warning
05 Reserved
06 No trip lock
07 No warning
08 Speed ≠ ref.
09 Local control
10 Out of range
11 Not running
12 No function
13 Voltage OK
14 Current OK
15 Thermal-level OK
Table 3.7 Status Word
16-05 Main Actual Value [%]
Range: Function:
0 % [-200 - 200 %] View the 2 byte word sent with the status
*
word to the bus master reporting the
main actual value.
16-09 Custom Readout
Range:
0 CustomRea- [0 - 9999
doutUnit CustomRea-
*
doutUnit]
3.12.2 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW [0 - 1000 Displays the actual motor power in kW.
*
kW] The value shown is calculated on the basis
of the actual motor voltage and motor
current.
16-11 Power [hp]
Range: Function:
0 hp [0 - 1000 View the actual motor power in hp. The
*
hp] value shown is calculated based on the
actual motor voltage and motor current.
MG18B502
Programming Guide
Bit = 1
Ready
Ready
Enable
Trip
Warning
–
Trip lock
Warning
Speed = ref.
Bus control
Frequency OK
Running
No function
Above limit
Above limit
Above limit
Function:
View the user-defined readouts
as defined in
parameter 0-30 Custom Readout
Unit, parameter 0-31 Custom
Readout Min Value, and
parameter 0-32 Custom Readout
Max Value.
