Parameters
5-13 Terminal 29 Digital Input
Parameter for configuring the input function on input terminal
29.
Option:
[60] Counter A (up)
[61] Counter A (down)
[62] Reset Counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset Counter B
[101] Sleep
[120] Lead Pump Start
[121] Lead Pump Alternation
[130] Pump 1 Interlock
[131] Pump 2 Interlock
[132] Pump 3 Interlock
[133] Pump 4 Interlock
[134] Pump 5 Interlock
3.6.3 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals.
5-34 On Delay, Digital Output
Range: Function:
0.01 s [0 - 600 s] Enter the delay time before the digital
*
output is switched on. The digital output
(terminal 42/45) condition must not be
interrupted during the delay time.
5-35 Off Delay, Digital Output
Range: Function:
0.01 s [0 - 600 s] Enter the delay time before the digital
*
output is switched off. The digital output
(terminal 42/45) condition must not be
interrupted during the delay time.
3.6.4 5-4* Relays
Parameters for configuring the timing and the output
functions for the relays.
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array
parameter. When parameter 0-03 Regional Settings is set to [0]
International, the default value is [9] Alarm. When
parameter 0-03 Regional Settings is set to [1] North America, the
default value is [160] No alarm.
Option: Function:
[0] No operation
MG18B502
Programming Guide
5-40 Function Relay
Array (Relay 1 [0], Relay 2 [1])
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array
Function:
parameter. When parameter 0-03 Regional Settings is set to [0]
International, the default value is [9] Alarm. When
parameter 0-03 Regional Settings is set to [1] North America, the
default value is [160] No alarm.
Option:
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[12]
[13]
[14]
[16]
[17]
[19]
Danfoss A/S © 04/2018 All rights reserved.
Function:
Control Ready The control board receives supply
voltage.
Drive ready The frequency converter is ready for
operation and applies a supply signal on
the control board.
Drive ready/ The frequency converter is ready for
remote control operation in auto-on mode.
Standby / no The frequency converter is ready for
warning operation. No start or stop command is
given. No warnings are present.
Drive running The motor runs.
Running / no The motor runs, and no warnings are
warning present.
Run in The motor runs within the programmed
range/no current ranges, see
warning parameter 4-50 Warning Current Low and
parameter 4-51 Warning Current High. No
warnings are present.
Run on ref/no The motor runs at reference speed and
warning with no warnings.
Alarm An alarm activates output.
Alarm or An alarm or warning activates output.
warning
Out of current The motor current is outside the ranges
range set in parameter 4-50 Warning Current
Low and parameter 4-51 Warning Current
High.
Below current, The motor current is lower than the limit
low set in parameter 4-50 Warning Current
Low.
Above current, The motor current is higher than the
high limit set in parameter 4-51 Warning
Current High.
Below speed, The frequency converter output speed is
low lower than the limit set in
parameter 4-40 Warning Freq. Low.
Above speed, The frequency converter output speed is
high higher than the limit set in
parameter 4-41 Warning Freq. High.
Below The feedback is lower than the limit set
feedback, low in parameter 4-56 Warning Feedback Low.
3 3
