Parameters
1-17 Voltage filter time const.
Range: Function:
Size [0.001 - 1 Machine supply voltage filter time
related s] constant is used for reducing the
*
influence of high frequency ripples and
system resonances in the calculation of
machine supply voltage. Without this
filter, the ripples in the currents can
distort the calculated voltage and affect
the stability of the system.
3.2.4 1-2* Motor Data I
This parameter group comprises input data from the
nameplate on the connected motor.
NOTICE
These parameters cannot be adjusted while the motor is
running.
NOTICE
Changing the value of these parameters affects the
setting of other parameters.
1-20 Motor Power
Enter the nominal motor power in kW/hp according to the motor
nameplate data. The default value corresponds to the nominal
rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Option:
[2] 0.12 kW - 0.16 hp
[3] 0.18 kW - 0.25 hp
[4] 0.25 kW - 0.33 hp
[5] 0.37 kW - 0.5 hp
[6] 0.55 kW - 0.75 hp
[7] 0.75 kW - 1 hp
[8] 1.1 kW - 1.5 hp
[9] 1.5 kW - 2 hp
[10] 2.2 kW - 3 hp
[11] 3 kW - 4 hp
[12] 3.7 kW - 5 hp
[13] 4 kW - 5.4 hp
[14] 5.5 kW - 7.5 hp
[15] 7.5 kW - 10 hp
[16] 11 kW - 15 hp
[17] 15 kW - 20 hp
[18] 18.5 kW - 25 hp
[19] 22 kW - 30 hp
[20] 30 kW - 40 hp
[21] 37 kW - 50 hp
[22] 45 kW - 60 hp
[23] 55 kW - 75 hp
[24] 75 kW - 100 hp
MG18B502
Programming Guide
1-20 Motor Power
Enter the nominal motor power in kW/hp according to the motor
nameplate data. The default value corresponds to the nominal
rated output of the unit.
This parameter cannot be adjusted while the motor is running.
Option:
[25]
[26]
1-22 Motor Voltage
Range:
Size
related
*
1-23 Motor Frequency
Range:
Size
related
*
1-24 Motor Current
Range:
Size
related
*
Function:
1-25 Motor Nominal Speed
Range:
Size related
1-26 Motor Cont. Rated Torque
Range:
0 Nm
*
Danfoss A/S © 04/2018 All rights reserved.
90 kW - 120 hp
110 kW - 150 hp
Function:
[50 - 1000 Enter the nominal motor voltage
V] according to the motor nameplate
data. The default value corresponds to
the nominal rated output of the unit.
Function:
[20 - Select the motor frequency value from the
400 motor nameplate data. For 87 Hz operation
Hz] with 230/400 V motors, set the nameplate
data for 230 V/50 Hz. Adapt
parameter 4-14 Motor Speed High Limit [Hz]
and parameter 3-03 Maximum Reference to the
87 Hz application.
Function:
[ 0.01 - Enter the nominal motor current
1000.00 A] value from the motor nameplate
data. This data is used for calculating
motor torque, motor thermal
protection, and so on.
Function:
[50 - 60000 Enter the nominal motor speed
*
RPM] value from the motor nameplate
data. This data is used for
calculating automatic motor
compensations.
Function:
NOTICE
[0.1 -
10000.0 Nm]
Changing this parameter affects
settings of other parameters.
This parameter is available only when
parameter 1-10 Motor Construction is set
to options that enable permanent motor
mode.
3 3
Function:
