Danfoss VLT HVAC Basic Drive FC 101 Programming Manual page 75

Parameters
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
[83] Broken Belt
3.9.6 13-5* States
13-51 SL Controller Event
Array [20]
Option: Function:
Select the boolean input (true or
false) to define the smart logic
controller event.
See parameter 13-02 Stop Event for
further descriptions of options and
their functions.
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[39] Start command
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
MG18B502
Programming Guide
13-51 SL Controller Event
Array [20]
Option:
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-52 SL Controller Action
Array [20]
Option:
[100] ResetAlarm
[0] Disabled
*
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[10] Select preset ref
0
[11] Select preset ref
1
[12] Select preset ref
2
[13] Select preset ref
3
[14] Select preset ref
4
[15] Select preset ref
5
[16] Select preset ref
6
[17] Select preset ref
7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
Danfoss A/S © 04/2018 All rights reserved.
Function:
Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (defined in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions
are available for selection:
Changes the active set-up
(parameter 0-10 Active Set-up) to set-up
1.
Changes the active set-up
(parameter 0-10 Active Set-up) to set-up
2.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active
preset reference is changed, it merges
with other preset reference commands
coming from either the digital inputs or
via a fieldbus.
Selects ramp 1.
Selects ramp 2.
Issues a start command to the
frequency converter.
Issues a start reverse command to the
frequency converter.
Issues a stop command to the
frequency converter.
3 3
73
