4.4 Extended Status Words

Bit Hex Dec
0 1 1
1 2 2
2 4 4
3 8 8
4 10 16
5 20 32
6 40 64
7 80 128
8 100 256
9 200 512
10 400 1024
11 800 2048
12 1000 4096
13 2000 8192
14 4000 16384
15 8000 32768
16 10000 65536
17 20000 131072
18 40000 262144
19 80000 524288
20 100000 1048576
21 200000 2097152
22 400000 4194304
23 800000 8388608
24 1000000 16777216
25 2000000 33554432
26 4000000 67108864
27 8000000 134217728
28 10000000 268435456
29 20000000 536870912
30 40000000 1073741824
31 80000000 2147483648
Table 4.5 Extended Status Words
MG18B502
Programming Guide
Parameter 16 Parameter 16-95
-94 Ext. Ext. Status Word
Status Word 2
Ramping Off
AMA running Hand/Auto
Start CW/CCW 0
0 0
0 0
Feedback
0
high
Feedback low 0
Output
Control Ready
current high
Output
Drive Ready
current low
Output
frequency Quick Stop
high
Output
DC Brake
frequency low
0 Stop
0 0
Freeze Output
Braking
Request
0 Freeze Output
OVC active Jog Request
AC brake Jog
0 Start request
0 Start
Reference
0
high
Reference low Start Delay
0 Sleep
0 Sleep boost
0 Running
0 Bypass
0 Fire Mode
0 External Interlock
Firemodelimi-
0
texceed
0 FlyStart Active
0 0
0 0
Database
0
busy
Danfoss A/S © 04/2018 All rights reserved.

4.5 List of Warnings and Alarms

WARNING/ALARM 2, Live zero error
This warning or alarm only appears if parameter 6-01 Live
Zero Timeout Function is configured. The signal on 1 of the
analog inputs is less than 50% of the minimum value
programmed for that input. This condition can be caused
by broken wiring or a faulty device sending the signal.
Troubleshooting
•
Check connections on all the analog input
terminals. Control card terminals 53 and 54 for
signals, terminal 55 common.
•
Check that the frequency converter programming
matches the analog signal type.
WARNING/ALARM 3, No motor
No motor is connected to the output of the frequency
converter. Check the cable connection between the
frequency converter and the motor.
WARNING/ALARM 4, Mains phase loss
A phase is missing on the supply side, or the mains
voltage imbalance is too high. This message also appears
for a fault in the input rectifier on the frequency converter.
Options are programmed at parameter 14-12 Function at
Mains Imbalance.
Troubleshooting
•
Check the supply voltage and supply currents to
the frequency converter.
WARNING/ALARM 7, DC overvoltage
If the DC-link voltage exceeds the limit, the frequency
converter trips after a time.
Troubleshooting
•
Extend the ramp time.
•
Activate functions in parameter 2-10 Brake
Function.
•
Activate overvoltage control in
parameter 2-17 Over-voltage Control.
WARNING/ALARM 8, DC under voltage
If the DC-link voltage (DC) drops below the undervoltage
limit, the frequency converter trips after a fixed time delay.
The time delay varies with unit size.
Troubleshooting
•
Check that the supply voltage matches the
frequency converter voltage.
•
Perform an input voltage test.
WARNING/ALARM 9, Inverter overloaded
The frequency converter is about to cut out because of an
overload (too high current for too long). The counter for
electronic, thermal inverter protection issues a warning at
90% and trips at 100%, while issuing an alarm. The
frequency converter cannot be reset until the counter is
below 90%.
The fault is that the frequency converter is overloaded by
more than 100% for too long.
