Parameters
3.5.3 4-5* Adj. Warnings
Define adjustable warning limits for current. Warnings are
shown on the display, programmed output, or fieldbus.
4-50 Warning Current Low
Range: Function:
0 A [ 0 - 500 Enter the I
LOW
A] drops below this limit, a bit in the status word is
set. This value can also be programmed to
produce a signal on the digital output or the
relay output.
4-51 Warning Current High
Range: Function:
Size [ 0.0 - Enter the I
related 500.00 A] current exceeds this limit, a bit in the
*
status word is set. This value can also
be programmed to produce a signal on
the digital output or the relay output.
4-54 Warning Reference Low
Range: Function:
-4999 [-4999 - Enter the lower reference limit. When the
*
4999 ] actual reference drops below this limit, the
display indicates Ref
in parameter 16-94 Ext. Status Word. The
output relay or the digital output can be
configured to indicate this warning. The LCP
warning indicator light is not turned on when
this parameter set limit is reached.
4-55 Warning Reference High
Range: Function:
4999 [-4999 - Use this parameter to set a higher limit for the
*
4999 ] reference range.
When the actual reference exceeds this limit,
the display reads Reference High. Warning bit
19 is set in parameter 16-94 Ext. Status Word.
The output relay or the digital output can be
configured to indicate this warning. The LCP
warning indicator light is not turned on when
this parameter set limit is reached.
