3.12.5 16-6* Inputs and Outputs

16-60 Digital input
Range: Function:
0 [0 - 65535 ] View actual state of the digital inputs 18, 19, 27
*
and 29.
Bits definition
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6~15
16-61 Terminal 53 Setting
Option: Function:
View the setting of input terminal 53. Current
= 0; Voltage = 1.
[0] Current mode
*
[1] Voltage mode
16-62 Analog Input AI53
Range: Function:
1.000 [0.000 - 20.000 ] View the actual value at input 53.
*
16-63 Terminal 54 Setting
Option: Function:
View the setting of input terminal 54. Current
= 0; Voltage = 1.
[0] Current mode
*
[1] Voltage mode
16-64 Analog Input AI54
Range: Function:
1.000 [0.000 - 20.000 ] View the actual value at input 54.
*
16-65 Analog Output AO42 [mA]
Range: Function:
0.000 mA [0.000 - View the actual value at output 42 in
*
20.000 mA] mA. The value shown reflects the
selection in 6-90 Terminal 42 Mode and
6-91 Terminal 42 Analog Output.
16-66 Digital Output
Range: Function:
0 [0 - View the binary value of all digital outputs.
*
15 ]
Definition:
X: Not used
0: Low
1: High
VLT HVAC Basic Drive Programming Guide
Unused
Unused
Digital input term. 29
Digital input term. 27
Digital input term. 19
Digital input term. 18
Unused
®
MG.18.B1.02 - VLT is a registered Danfoss trademark
16-66 Digital Output
Range: Function:
XX None used
X0 Terminal 42 not used, Terminal 45
low
X1 Terminal 42 not used, Terminal 45
High
0X Terminal 42 low, Terminal 45 not
used
0 Terminal 42 low, Terminal 45 low
1 Terminal 42 low, Terminal 45 high
1X Terminal 42 high, Terminal 45 not
used
10 Terminal 42 high, Terminal 45 low
11 Terminal 42 high, Terminal 45 high
16-71 Relay Output [bin]
Range: Function:
0 [0 - 65535 ] View the setting of the relay.
*
Bits definition:
Bit 0~2
Bit 3
Bit 4
Bit 5~15
16-72 Counter A
Range: Function:
0.0 [-32768 - View the present value of Counter A. Counters
*
32767 ] are useful as comparator operands, see
13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1*) or by
using an SLC action (13-52 SL Controller Action).
16-73 Counter B
Range: Function:
0.0 [-32768 - View the present value of Counter B. Counters
*
32767 ] are useful as comparator operands
(LC-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1*) or by
using an SLC action (13-52 SL Controller Action).
16-79 Analog Output AO45
Range:
0.000 mA [0.000 - 20.000 mA]
*
Unused
Relay 02
Relay 01
Unused
Function:
